Model 339 Specifications
Freezing Cylinder
Two, 2.8 quart (2.7 liter) volume.
Mix Hopper
Two, 20 quart (18.9 liter) capacity.
Beater Motor
Two, 1.0 hp.
Refrigeration Unit
Two, approximately 6,000 btu/hr compressors.
Refrigerant R404A.
One independent (SHR) compressor, approximately
400 btu/hr. Refrigerant R134a.
(BTU's may vary based on compressor used.)
Electrical
Two dedicated connections.
Maximum Minimum Circuit
Fuse Size Ampacity
Electrical
Left
Right Left Right
208-230/60/1 Air 25 20 19 14
208-230/60/1 Water 20 20 16 14
208-230/60/3 Air 20 15 16 12
208-230/60/3 Water 20 15 14 12
This unit is manufactured in other electrical
characteristics. Refer to the Distributor Data Book for
availability. (For exact electrical information, always refer
to the data label of the unit.)
Air Cooled
Clearance: 3" (7.6 cm.) around all sides. A deflector has
been added to underside preventing recirculation of
warm air. This will assure proper air flow across
condensers to obtain optimum performance.
Water Cooled
Water inlet and drain connections under side of base 1/2"
FPT.
Dimensions
Width: 26-7/16" (67.2 cm.)
Depth: 33" (83.8 cm.)
Height: 59-7/8" (152.1 cm.)
Floor Clearance: 7-1/2" (19.1 cm.) mounted on
standard casters.
Approximate Weights
Net: 608 Ibs. (275.8 kgs.) Crated: 698 Ibs. (316.6 kgs.),
48.1 cu. ft. (1.3 cu. m.)
Availability and specifications are subject to change
without notice.
This unit is designed and constructed to meet stringent
safety and sanitation requirements for NSF and UL
