Models 751/8751 Specifications
Freezing Cylinder
One, 3.4 quart (3.2 liter) volume.
Mix Hopper
One, 20 quart (18.9 liter) capacity.
Beater Motor
One,1.5 hp.
Refrigeration Unit
One, approximately 9,500 btu/hr compressor.
Refrigerant R404A.
One independent (SHR) compressor, approximately
400 btu/hr. Refrigerant R134a.
(BTU's may vary based on compressor used.)
Electrical
Electrical One dedicated connection.
Maximum Minimum
Model 751 Fuse Size Circuit Ampacity
208-230/60/1 Air 35 26
208-230/60/1 Water 30 24
208-230/60/3 Air 25 19
208-230/60/3 Water 20 17
Model 8751
208-230/60/1 Air 35 28
208-230/60/1 Water 35 25
208-230/60/3 Air 25 21
208-230/60/3 Water 25 18
These units are manufactured in other electrical
characteristics. Refer to the Distributor Data Book for
availability. (For exact electrical information, always refer to
the data label of the unit.)
Air Cooled
Clearance: 3" (7.6 cm.) around all sides. A deflector has
been added to underside preventing recirculation of warm air.
This will assure proper air flow across condensers to obtain
optimum performance.
Water Cooled
Water inlet and drain connections 3/8" FPT.
Dimensions
Width: 18-7/16" (46.8cm.)
Depth: 31-3/16" (79.2 cm.)
Height: 59-7/8" (152.1 cm.)
Floor Clearance: 7-1/2" (19.1 cm.) mounted on
standard casters.
Approximate Weights
Model 751:
Net: 455 Ibs. (201.9 kgs.) Crated: 476 Ibs. (215.9 kgs.),
35.4 cu. ft. (.99 cu. m.)
Model 8751:
Net: 480 Ibs. (217.7 kgs.) Crated: 501 Ibs. (227.2 kgs.),
35.4 cu. ft. (.99 cu. m.)
Availability and specifications are subject to change
without notice.
These units are designed and constructed to meet stringent
safety and sanitation requirements for NSF and UL.
