Model 794 Specifications
Freezing Cylinder
Two, 3.4 quart (3.2 liter) volume.
Mix Hopper
Two, 14 quart (13.3 liter) capacity.
Beater Motor
Two, 1.5 hp.
Refrigeration Unit
Two, approximately 9,500 btu/hr compressors.
Refrigerant R404A.
One independent (SHR) compressor, approximately
400 btu/hr. Refrigerant R134a.
(BTU's may vary based on compressor used.)
Electrical
Two dedicated connections.
Maximum Minimum Circuit
Fuse Size Ampacity
Electrical
Left Right Left Right
208-230/60/1 Air 35 35 28 23
208-230/60/1 Water 35 35 25 23
208-230/60/3 Air 25 20 20 16
208-230/60/3 Water 25 20 17 16
This unit is manufactured in other electrical characteristics.
Refer to the Distributor Data Book for
availability. (For exact electrical information, always refer to
the data label of the unit.)
Air Cooled
Clearance: 3" (7.6 cm.) around all sides. A deflector has
been added to underside preventing recirculation of warm air.
This will assure proper air flow across condensers to obtain
optimum performance.
Water Cooled
Water inlet and drain connections under side of base 1/2"
FPT.
Dimensions
Width: 20-7/16" (51.9cm.)
Depth: 33-3/16" (84.3 cm.)
Height: 59-1/2" (151.1 cm.)
Floor Clearance: 7-1/2" (19.1 cm.) mounted on
standard casters.
Approximate Weights
Net: 690 Ibs. (312.9kgs.) Crated: 747 Ibs. (338.8 kgs.), 39.1
cu. ft. (1.1 cu. m.)
Availability and specifications are subject to change
without notice.
This unit is designed and constructed to meet stringent safety
and sanitation requirements for NSF and UL.
