Taylor C858 User Manual

13
C854 Exploded View
Item Part No. Description Qty Function
Warr.
Class
1 027408 Screw-10-32X1/4 SLTD Truss 8 Secures the panels to the frame. 000
2 X84971 Can A.-Grease-L 1 Container for grease. 103
3 X84248 Shroud A.-Upper*LFT 1 Metal bracket that the grease can slides
into, securing it next to the lower grill plate.
103
4 X84323 Shroud A. - Lower - Side 2 Left/right access panel. 103
5 070695 Screw-10-32X1/2 PHIL 4 Fastens bumper onto panel. 000
6 084549 Bumper 1 Protects grill from damage. 000
7 X73600-SER Kit A.-Grease Shield 4 Fastens grease shields to rear shroud. 000
8 082959 Panel-Rear 1 Provides access to internal components for
service and cleaning.
103
9 024298 Screw-10-32X3/8 SLTD Truss 54 Secures the panel to the frame. 000
10 084250 Panel-Side-Right 1 Provides access to internal components for
service and cleaning.
103
11 X84526 Can A.-Grease-R 1 Container for grease. 103
12 X84246 Shroud A.-Upper*RT 1 Metal bracket that the grease can slides
into, securing it next to the lower grill plate.
103
13 078377-1 Caster-5 7-5/8 Stem 2 Allows grill mobility. 103
14 087002 Pin-Cotter 1/8 x 1 in. 8 Secures the outrigger to the caster. 000
15 086984 Outrigger A.-Right 1 Stabilizes grill. 000
16 073240-3 Caster-5 7-5/8 Stem-Swivel w/
Lock
2 Prevents grill movement. 103
17 076989-WP Switch-Rocker- DPST 10A 1 Activates power to the grill and the exhaust
fans.
103
18 086985 Outrigger-Left 1 Stabilizes grill. 000
19 X84523 Door A.-Lower 1 Controls all functions of the grill. - - -
20 X85623-SER Touchscreen A. 1 Controls all functions of the grill. - - -
21 068583 Cover A.-USB Waterproof 2 Protects USB port from water damage. 103
22 076012 Button-Operator- Black 2 Activates the Cook cycle, keeps upper
platen in the closed position, and displays
the message STANDBY on the control.
When pressed twice with 1-second intervals
between presses, the upper platen will
automatically lower into STANDBY position.
000
23 076011 Button-Operator- Red 2 Cancels the Standby mode, raises the upper
platen, and deactivates the Cook cycle.
000
24 X85465 Shield A.-Rear-GRS 2 Prevents grease migration. 000
25 084251 Panel-Side-Left 1 Provides access to internal components for
service and cleaning.
103
26 085441 Spacer Bumper 1 Protects grill from damage. 000
27 084550 Bumper 1 Protects grill from damage. 000
