C856 Exploded View
Item Part No. Description Qty Function Warr. Class
1 027408 Screw-10-32X1/4 SLTD Truss 16 Secures the panels to the frame. 103
2 X84971 Can A.-Grease-L 2 Container for grease. 103
3 X84248 Shroud A.-Upper*L 2 Metal bracket that the grease can slides
into, securing it next to the lower grill plate.
103
4 X84323 Shroud A. - Lower - Side 4 Left/right access panel. 103
5 084251 Panel-Side-Left 1 Provides access to internal components for
service and cleaning.
103
6 070695 Screw-10-32X1/2 Phil 4 Fastens bumper onto panel. 000
7 084549 Bumper 1 Protects grill from damage. 000
8 X73600-SER Kit A.-Grease Shield 4 Fastens grease shields to rear shroud. 000
9 084215 Panel-Rear 1 Provides access to internal components for
service and cleaning.
103
10 024298 Screw-10-32X3/8 SLTD Truss 54 Secures the panel to the frame. 000
11 X85465 Shield A.Rear GRS 2 Prevents grease migration.
12 078377 Caster-5 7-5/8 Stem 2 Allows grill mobility. 103
13 084250 Panel-Side-Right 1 Provides access to internal components for
service and cleaning.
103
14 X84526 Can A.-Grease-R 2 Container for grease. 103
15 X84246 Shroud A.-Upper*R 2 Metal bracket that the grease can slides
into, securing it next to the lower grill plate.
103
16 073240 Caster-5 7-5/8 Swivel w/Lock 2 Prevents grill movement. 103
17 076989-WP Switch-Rocker- DPST 10A 1 Activates power to the grill and the exhaust
fans.
103
18 X85623-SER Touchscreen A. 2 Controls all functions of the grill. - - -
19 X84504 Door A.-Welded 1 Houses the controls and the fan interlock
switch.
103
20 068583 Cover A.-USB Waterproof 2 Protects USB port from water damage. 103
21 076012 Button-Operator- Black 2 Activates the cook cycle, keeps the upper
platen in the closed position, and displays
the message STANDBY on the control.
When pressed twice with 1-second intervals
between presses, the upper platen will
automatically lower into the Standby
position.
000
22 076011 Button-Operator- Red 2 Cancels the Standby mode, raises the upper
platen, and deactivates the Cook cycle.
000
23 079150 Nut-10-32 Whiz Flange Nut 2 Secures the spacer to the bumper. 000
24 085441 Spacer Bumper 1 Protects grill from damage. 000
25 084550 Bumper 1 Protects grill from damage. 000
26 033944 Screw-10-32x3/4 SLTD Truss 2 Secures the spacer to the bumper. 000
