C860 Exploded View
Item Part No. Description Qty. Function
Warr.
Class
1 027408 Screw-10-32X1/4 SLTD Truss 24 Secures the panels to the frame. 103
2 X84971 Can A.-Grease-L 3 Container for grease. 103
3 X84248 Shroud A.-Upper*L 3 Metal bracket that the grease can slides into,
securing it next to the lower grill plate.
103
4 X84323 Shroud A. - Lower - Side 6 Left/right access panel. 103
5 070695 Screw-10-32X1/2 Phil 4 Fastens bumper onto panel. 000
6 084549 Bumper 1 Protects grill from damage. 000
7 X73600-SER Kit A.-Grease Shield 6 Fastens grease shields to rear shroud. 000
8 X85465 Shield A.-Rear GRS 3 Prevents grease migration.
9 085963 Panel-Rear 1 Provides access to internal components for
service and cleaning.
103
10 024298 Screw-10-32X3/8 SLTD Truss 54 Secures the panel to the frame. 000
11 084250 Panel-Side-Right 1 Provides access to internal components for
service and cleaning.
103
12 X84526 Can A.-Grease-R 3 Container for grease. 103
13 X84246 Shroud A.-Upper*R 3 Metal bracket that the grease can slides into,
securing it next to the lower grill plate.
103
14 078377 Caster-5 7-5/8 Stem 2 Allows grill mobility. 103
15 073240 Caster-5 7-5/8 Swivel W/Lock 2 Prevents grill movement. 103
16 076989-WP Switch-Rocker- DPST 10A 1 Activates power to the grill and the exhaust fans. 103
17 X85623-SER Touchscreen A. 3 Controls all functions of the grill. - - -
18 X85761 Door A.-Welded 1 Houses controls and the fan interlock switch. 103
19 068583 Cover A.-USB Waterproof 3 Protects USB port from water damage. 103
20 076012 Button-Operator- Black 3 Activates the Cook cycle, keeps the upper platen
in the closed position, and displays the message
STANDBY on the control. When pressed twice
with 1-second intervals between presses, the
upper platen will automatically lower into the
STANDBY position.
000
21 076011 Button-Operator- Red 3 Cancels the Standby mode, raises the upper
platen, and deactivates the Cook cycle.
000
22 084251 Panel-Side-Left 1 Provides access to internal components for
service and cleaning.
103
23 085447 Spacer Bumper 1 Protects grill from damage. 000
24 084613 Bumper 1 Protects grill from damage. 000
25 033944 Screw-10-32x3/4 SLTD Truss 2 Secures the spacer to the bumper. 000
