C852 Exploded View
Item Part No. Description Qty. Function
Warr.
Class
1 027408 Screw-10-32X1/4 SLTD Truss 16 Secures the panels to the frame. 000
2 X84969 Can A.-Grease-L 2 Container for grease. 103
3 X84224 Shroud A.-Upper*LFT 2 Metal bracket that the grease can slides into,
securing it next to the lower grill plate.
103
4 X84325 Shroud A. - Lower - Left 4 Left/right access panel. 103
5 070695 Screw-10-32X1/2 PHIL 4 Fastens bumper onto panel. 000
6 084549 Bumper 1 Protects grill from damage. 000
7 X73600-SER Kit A.-Grease Shield 4 Fastens grease shields to rear shroud. 000
8 084215 Panel-Rear 1 Provides access to internal components for
service and cleaning.
103
9 024298 Screw-10-32X3/8 SLTD Truss 54 Secures the panel to the frame. 000
10 082958 Panel-Side-Right 1 Provides access to internal components for
service and cleaning.
103
11 078377 Caster-5 7-5/8 Stem 2 Allows grill mobility. 103
12 X84608 Can A.-Grease-R 2 Container for grease. 103
13 X84225 Shroud A.-Upper-Right 2 Metal bracket that the grease can slides into,
securing it next to the lower grill plate.
103
14 073240 Caster-5 7-5/8 Swivel w/Lock 2 Prevents grill movement when the lock is used. 103
15 076989-WP Switch-Rocker- DPST 10A 1 Activates power to the grill and the exhaust
fans.
103
16 X84265-23 Control A.-Right 1 Controls all functions of the grill. - - -
17 X85623-SER Touchscreen A. 1 Controls all functions of the grill. - - -
18 X84255 Door A.-Welded 2 Houses the controls and the fan interlock
switch.
103
19 068583 Cover A.-USB Waterproof 2 Protects USB port from water damage. 103
20 076012 Button-Operator- Black 2 Activates the Cook cycle, keeps the upper
platen in the closed position, and displays the
message STANDBY on the control. When
pressed twice with 1-second intervals between
presses, the upper platen will automatically
lower into the Standby position.
000
21 076011 Button-Operator- Red 2 Cancels the Standby mode, raises the upper
platen, and deactivates the Cook cycle.
000
22 079150 Nut-10-32 Whiz Flange Lock 2 Secures the spacer to the bumper. 000
23 082957 Panel-Side-Left 1 Provides access to internal components for
service and cleaning.
103
24 085447 Space Bumper 1 Protects grill from damage. 000
25 084613 Bumper 1 Protects grill from damage. 000
26 033944 Screw-10-32x3/4 SLTD Truss 2 Secures the spacer to the bumper. 000
27 X85465 Shield A.-Rear-GRS 2 Prevents grease migration. 000
