Taylor Intelli Gap User Manual

Parts List
+ Available Separately, NNN = Not a Service Item
168
Parts List
McDonald's Intelligap Grills
150720
Model C832, C834, C842, & C844 Electric Grills: C83223G000 - 208V 60HZ 3PH, C83228G000 240V 60HZ 3PH, C82375GW00 400V 50HZ
3PH ROHS Compliant, C83475GW00 400V 50HZ 3N (4 Wire) Stubby, C84223G000 208V 60HZ 3PH, C84260GW00 220/380V 60 HZ
3PH-4, C84275GW00 400V 50HZ 3N~(4 Wire), C84278GW00 220V 50/60HZ 3PH, C84475GW00 400V 50HZ 3N~(4 Wire) Stubby
DESCRIPTION PART
NUMBER
QTY.
C832
-23
QTY.
C832
-28
QTY.
C832
-75
QTY.
C834
-75
QTY.
C842
-23
QTY.
C842
-60
QTY.
C842
-75
QTY.
C842
-78
QTY.
C844
-75
WARR.
CLASS
REMARKS
208V
60HZ
3PH
240V
60HZ
3PH
400V
50HZ
3N~
400V
50HZ
3N~
208V
60HZ
3PH
220/
380V
60HZ
3PH
400V
50HZ
3N~
220V
50/60
3PH
400V
50HZ
3N~
ARM A.-TUBE *C832* LEFT X72475-L 1 1 1 1 103
+SEAL-ARM *M32/35* 079952 2 2 2 2 000
ARM A.-TUBE *C832* RIGHT X72475-R 1 1 1 1 103
+SEAL-ARM *M32/35* 079952 2 2 2 2 000
ARM A.-TUBE LEFT X72771-L 2 2 2 2 2 103
ARM A.-SUPPORT *C844* LEFT X72772-L 2 2 2 2 103
ARM A.-SUPPORT *C844* RIGHT X72772-R 2 2 2 2 103
ARM A.-TAIL *C842* X72446 2 2 2 2 103
TAB-SWITCH ARM *C842* 072552 2 2 2 2 000
ARM A.-TUBE RIGHT X72771-R 1 1 1 1 1 103
ARM A.-SUPPORT *C844* LEFT X72772-L 1 1 1 1 103
ARM A.-SUPPORT *C844* RIGHT X72772-R 1 1 1 1 103
ARM A.-TAIL *C842* X72446 1 1 1 1 103
TAB-SWITCH ARM *C842* 072552 1 1 1 1 000
BACKSPLASH A.-*C832/C835* X73126 1 1 1 1 103
BACKSPLASH A. X72954 1 1 1 1 1 103 S/N K8102227 & UP
REPLACED X72410
BAR A.-RELEASE *C832/C835* X73315 4 4 4 4 103
BAR A.-RELEASE MATERIAL*832/35 X73118 4 4 4 4 103
BAR A.-RELEASE MATERIAL X72843 6 6 6 6 3 103
+NUT-10-32 FLANGE LOCKNUT 020983 18 18 18 18 9 000
+SCREW-SHOULDER 10-32X1/4 072849 6 000
BAR-BELLY 075663-SP 1 1 1 1 1 1 1 1 1 103
+SCREW-3/8-16X1 HEX HEAD CAP 079145 2 2 2 2 2 2 2 2 2 000
+WASHER-3/8 USS FLAT CR3 000653 2 2 2 2 2 2 2 2 2 000
BEARING 3/4 ID-SELF ALIGN 078730 4 4 4 4 6 6 6 6 6 103
BEARING .753 X 1.000 X 2.000 072541 6 6 6 6 6 000
BEARING .753 X 1.000 X 2.500 074398 4 4 4 4 103
BEARING-FLANGE 3/4 X 15/16 077042 8 8 8 8 12 12 12 12 12 000
