Taylor Intelli Gap User Manual

169
+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C844
-75
QTY.
C842
-78
QTY.
C842
-75
QTY.
C842
-60
QTY.
C842
-23
QTY.
C834
-75
QTY.
C832
-75
QTY.
C832
-28
QTY.
C832
-23
PART
NUMBER
BLOCK-CONTACT 1 NO *11/12/15 076013 4 4 4 4 6 6 6 6 6 103 PANEL A.-LIGHT BOX
BLOCK-TERMINAL 1P 073423 1 1 1 1 1 2 2 2 2 103
BLOCK-TERMINAL 2P .25 SPADE 051644 2 2 2 2 2 1 1 1 1 103 CONTROL A.-UPPER
BLOCK-TERMINAL 3P 20A, 300V 051331 1 1 1 1 1 1 103
BLOCK-TERMINAL 4P 1,2,L1,N 051647 1 1 1 1 1 1 1 1 1 103 CONTROL A.-UPPER
BUTTON-OPERATOR-BLACK 076012 2 2 2 2 3 3 3 3 3 103 PANEL A.-LIGHT BOX
BUTTON-OPERATOR-RED 076011 2 2 2 2 3 3 3 3 3 103 PANEL A.-LIGHT BOX
+GUARD-LENSE 075288 2 2 3 3 3 3 103
+LABEL-CONTROL PANEL-INTL SYMBL 075699-SYM 1 1 000
+LABEL-CONTROL PANEL-INTL SYMBL 075699SYM3 1 1 1 1 000
BRACKET A.-LATCH SWITCH X72715 2 2 2 2 2 103
BULLNOSE A. *****SEE DRIPEDGE X79036 X76585 1 1 1 1 103
BUSHING-SNAP 11/16 ID X 7/8OD 010548 6 6 6 6 12 11 11 12 11 103 PANEL A.-LIGHT BOX
BUSHING-SNAP 1-3/8ID X 1-3/4OD 027712 5 5 5 1 7 7 7 5 7 103
BUSHING-SNAP 15/16 ID X 1-3/32 023396 5 5 5 5 103
BUSHING-SNAP 1-5/8ID X 2 OD 043637 3 3 3 3 103
CABLE-ADJUST-PLATEN 072458 6 6 6 6 9 9 9 9 9 103
+CABLE-LON GATEWAY *C842* 072916-32 * * * * * * * 103 M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-42 * * * * * * * * * 103 M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-43 * 103 M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-52 * * * * * * * * * 103 M5057035 & PRIOR W/LON
CARD-GRILL OPERATION 072911 1 1 1 1 1 000
CARD-CHECKOUT MCD *C842/C844* 072941 1 1 1 1 1 1 1 1 1 000
CASTER-5" 7-5/8 STEM 078377 2 2 2 2 2 2 2 2 2 103
CASTER-GRILL 5" SWIVEL W/LOCK 073240 2 2 2 2 2 2 2 2 103
CLEVIS-ROD 1/2-20 THD 079777 2 2 2 2 3 3 3 3 3 103
CLIP-RELEASE MATERIAL-W/TAB 072673 8 8 8 8 9 9 9 9 9 000
COMPRESSOR-AIR-115V 60HZ 075506SER1 1 1 1 212 208V 60HZ 3PH
COMPRESSOR-AIR-230V SERV 032129SER2 1 1 1 1 1 1 212 400V 50HZ 3N~ (4 WIRE)
+ADAPTOR-1/4MPT X 1/4 OD TUBE 052563-2 1 1 1 1 1 1 1 1 1 103
+CROSS-1/4 FPT * 1.562 SQ 077339-M 1 1 1 103
+ ELBOW-1/4PT-STREET-BRASS 035573 1 1 1 103
+FITTING-1/4MPTX1/4OD TUBE 90DG 052560-2 1 1 1 1 1 1 1 1 1 103
+MANIFOLD A.-*C832* 073129 1 1 1 1 103
+PLUG-1/4MP BRASS 027747 1 1 1 1 1 1 1 1 1 103
