Taylor Intelli Gap User Manual

+ Available Separately, NNN = Not a Service Item
170
Parts List
McDonald's Intelligap Grills
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C844
-75
QTY.
C842
-78
QTY.
C842
-75
QTY.
C842
-60
QTY.
C842
-23
QTY.
C834
-75
QTY.
C832
-75
QTY.
C832
-28
QTY.
C832
-23
PART
NUMBER
+PLUG-HOLE 7/8 DIA. BLACK 010077 1 1 1 1 1 1 1 1 1 000
+PLUG-1/4 NPT-PARKER:VS219P-4 065156-6 1 1 1 103
+SWITCH-PRESSURE 240V,3HP 077879-C 1 1 1 1 103
+TANK-ACCUMULATOR 10LB-NPT 078820 1 1 1 1 103
+TEE-1/4FPT X 1/4MPT X 1/4FPT 021277 1 1 1 1 1 1 103
+TEE-1/4OD X 1/4OD X 1/4OD TUBE 052562 1 1 1 1 1 1 1 1 1 103
+TUBE-.170ID X .250OD R403021 10' 10' 10' 10' 10' 10' 10' 10' 10' 000
+VALVE-CHECK 1/4MP 020959 1 1 1 1 1 1 103
CONNECTOR A.- /951 X77018 1 103 C84275GW51 *AUSTRALIA*
CONNECTOR-MATE LOCK-3 CIR-PIN 044823 4 4 3 4 5 4 3 5 3 103 PANEL A.-LIGHT BOX
CONNECTOR-MATE LOCK-9 CIR-PIN 078020 2 2 2 2
3 3 3
3 103
CONTROL-GATEWAY-LON X72848-SER * * * * * * * * * 212 M5057035 & PRIOR W/LON
+BRACKET-LON CONTROL *842/844 072806 * * * 103 M5057035 & PRIOR W/LON
+BRACKET-LON CONTROL*842/8 072806-75 * * * 103 M5057035 & PRIOR W/LON
+BRACKET-LON CONTROL*C832/C83 073232-26 * * 103 M5057035 & PRIOR W/LON
+BRACKET-LON CONTROL*C832/C834 073232 * 103 M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-32 * * * * * * * 103 M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-42 * * * * * * * * * 103 M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-43 * 103 M5057035 & PRIOR W/LON
+CABLE-LON GATEWAY *C842* 072916-52 * * * * * * * * * 103 M5057035 & PRIOR W/LON
+FILTER-CORCOM 2VR1 032567 * * * * * * * * * 103 M5057035 & PRIOR W/LON
+FILTER-EMI-LINE-250V50/60HZL 073245 * * * * * 000 M5057035 & PRIOR W/LON
+SCREW-10X3/8 SLOTTED HEX WSH 015582 * * * * * * * * 000 M5057035 & PRIOR W/LON
+SCREW-6-32X5/8 UNSLTD HWH 041363 * * * * * * * * * 000 M5057035 & PRIOR W/LON
+SCREW-8X1/4 SLTD HEX WASHER 009894 * * * * * * * * 000 M5057035 & PRIOR W/LON
+TRANS.-CONT.-40VA 208/240V 053072 * * * * * * * * * 103 M5057035 & PRIOR W/LON
CONTROL-DISPLAY X72491-SER 2 2 2 2 3 3 3 3 3 212 DOOR A.-LOWER-DISPLAY
+GASKET-CONTROL *C842* 072914 2 2 2 2 3 3 3 3 000
+NUT-8-32 HEX M/S NUT SMALL 000969 4 4 4 4 6 6 6 6 6 000
+WASHER-#8 EXTERNAL TOOTH LOCK 000964 4 4 4 4 6 6 6 6 6 000
CONTROL-LIMIT W/SCREWS 078721 10 10 12 12 12 12 103 PLATEN A.-2600W
CONTROL-HI-LIMIT 550F NO RESET 074165 8 8 12 12 12 103 PLATEN A.-2450W
CONTROL-MOTOR INTERFACE X72436-SER 2 2 2 2 3 3 3 3 3 212 CONTROL A.-LOWER
+SCREW-6-32X5/8 UNSLTD HWH 041363 6 6 6 6 18 18 18 18 18 000
CORD-1.5MM-3 HAR7 16GA 60DEG.C 051656-158 1 1 1 1 NNN
