+ Available Separately, NNN = Not a Service Item
McDonald's Intelligap Grills Parts List
DESCRIPTION REMARKSWARR.
CLASS
QTY.
C844
-75
QTY.
C842
-78
QTY.
C842
-75
QTY.
C842
-60
QTY.
C842
-23
QTY.
C834
-75
QTY.
C832
-75
QTY.
C832
-28
QTY.
C832
-23
PART
NUMBER
CORD-2.6MM-5 HAR7 26A 60DEG C 054832-158 2 2 2 2 NNN
COVER A.-PLATEN *C832/C835* X73116 2 2 2 2 103
COVER A.-PLATEN *C832* X73117 2 2 2 2 103
BAR A.-RELEASE MATERIAL*832/ X73118 4 4 4 4 103
NUT-10-32 WHIZ FLANGE LOCKNU 020983 12 12 12 12 000
COVER A.-PLATEN *C842* X73365 3 3 3 3 3 103 REPLACED X72847
COVER-SHROUD RIGHT *C844* 072797 1 103
COVER-SHROUD LEFT *C844* 072798 1 103
COVER-SHROUD DOUBLE *M34* 074109 2 103
CYLINDER-AIR 6IN STROKE C/C 079160 2 2 2 2 3 3 3 3 3 103
DIAGRAM-WIRING *C832* 072522-23 1 000 208V 60HZ 3PH
DIAGRAM-WIRING *C832* 072522-28 1 000
DIAGRAM-WIRING *C832* 073295-75 1 1 000
DIAGRAM-WIRING 072826-23 1 000 208V 60HZ 3PH
DIAGRAM-WIRING *C842* 072861-60 1 000
DIAGRAM-WIRING 072861-75 1 000
DIAGRAM-WIRING *C842* 072826-78 1 1 000
DIAGRAM-WIRING 072700-75 1 000 400V 50HZ 3N~*FRANCE*
S92 C84275GWR3
DIAGRAM-WIRING 072745-75 1 000 400V 50HZ 3N~SERIES 92
C84275GWR0
DOOR A.-CONTROL *C832* X72485 1 1 1 1 103
DOOR A.-CONTROL X72431 1 1 1 1 1 103
DRIPEDGE A.-SERVICE X79036 1 1 1 1 103
E-RING-3/4 STEEL 077046 8 8 8 8 12 12 12 12 12 000
FASTENER-SNAP IN 1/4X15/16 078329 16 16 16 16 24 24 24 24 24 000
FILTER-CORCOM 2VR1 032567 2 2 2 2 3 3 3 3 3 103 USED W/LON UNITS S/N
M5057035 & PRIOR
FILTER-2 POLE *C842* 072887 1 1 1 000
FILTER A.-*C842* WHT/BLK X72727-40 1 1 1 000
FILTER A.-*M15* WHT/BLK X78996-40 1 1 103
FILTER A.-*M22E* WHT/BLK X79256 1 1 2 1 1 2 2 103
FITTING-1/4MPTX1/4OD TUBE 90DG 052560-2 5 5 5 5 7 7 7 7 7 103
FORM-QUALITY REPORT BY FAX 065712 1 1 1 1 1 1 1 1 1 000
FUSE-7 AMP MDQ-7 079837-070 1 1 1 000
+HOLDER-FUSE-15 A, 250 V 076299 1 1 1 103
