3. Installation and Wiring
3.1 Pre-installation inspection
3.1.1 Check outer packing
 Please check the outer packing for damage before unpacking, and check the machine model.
If there have something wrong, please don’t open it and contact your dealer.
 Please check the quantity of accessories, if there have something wrong, please contact your
dealer.
3.1.2 Check deliverables
 After unpacking, please check the deliverable for completeness and any apparent damage.
 If any item is missing or there is any damage, please contact your dealer.
3.2 Instrument Preparation
Please prepare tools and instruments following the Table 3-1 in advance.
Table 3-1 tools and instruments
Classify Tools and instruments
Installing
Percussion drill (φ6mm) Diagonal pliers Wire stripper
Wire cutters
（25mm²~35mm²）
Hydraulic
pliers（25mm²~35mm²
）
Cross screwdrivers
（M4、M6）
Universal
meter（600V）
Heat-shrinkable tubing Heat gun
Personal
safety
equitment
Protective gloves Protective shoes
