Table 3-1 PV allowance for SP
Solar Mate SP150-120 SP150-80 SP150-60 SP250-100 SP250-70
Applicable PV combiner box PVB150-8 PVB150-6 PVB150-4 PVB250-5 PVB250-3
PV open circuit voltage (Voc) 150 150 150 250 250
Max. PV short circuit current 70A 70A 40A 70A 70A
Maximum charging current (40℃)
120A 80A 60A 100A 70A
Maximum charging power 6720W 4480W 3360W 5600 W 3920W
Recommended PV 8000W 5280W 4000W 6600W 4400W
The Voc of PV array must never exceed 150V for SP150-YYY and 250V for
SP250-YYY ;The PV array Isc must not exceed 70A at any time.
The Voc or Vmpp of solar panel was rated at 25℃ with normal weather
condition. Along with temperature reduced, the Voc/Vmpp of solar array will
increase. Please consult with PV manufacturer for Voc/Vmpp of the lowest
possible environment temperature and making sure it is below 150VDC for
SP150-YYY and 250VDC for SP250-YYY.
 PV array with Isc up to 80A was recommended for SP series to allow for increase of Isc
caused by irradiance enhancement under certain condition.
 Please ensure the PV array used in the system operates within the MPPT operational window.
Following table shows effects of different PV array voltage.
Table 3-2 Effects of different PV array voltage
Model
Voltage Effect SP mode
SP150-120
Vmpp = 65VDC to
145VDC
Maximize the harvest of solar energy ChargingSP150-80
SP150-60
SP150-120
Voc > 145VDC
SP shut down when Vmpp is higher than
145VDC. Unit might damage if
Voc>150VDC
Overvoltage fault
SP150-80
SP150-60
SP250-100 Vmpp = 65VDC to
245VDC
Maximize the harvest of solar energy
Charging
SP250-70
SP250-100
Voc> 245VDC
SP shut down when Vmpp is higher than
245VDC. Unit might damage if
Voc>250VDC
Overvoltage fault
SP250-70
