TBS CROSSFIRE Micro TX - Page 20



● TBS GPS - Can only be powered by the BST 5V
● TBS CURRENT SENSOR - Provides VBatt but needs BST 5V to run itself
● TBS CROSSFIRE RX - Can be powered over one of the eight servo connectors or by BST 5V
● TBS CORE PRO / FPVISION - This is only device is providing 5V on the BST line
Power type:
BST 5V
VBATT
ESC BEC 5V
FC 5V
TBS CROSSFIRE
✔ PWR IN

✔ PWR IN

TBS BLACKBOX
✔ PWR IN


✔ PWR IN
TBS GPS
✔ PWR IN



TBS CORE PRO / FPVISION
✔ PWR OUT
✔ PWR IN


TBS CURRENT SENSOR
✔ PWR IN
✔ PWR
OUT


TBS BULLETPROOF ESC (Older
version, obsolete)


✔ PWR
OUT

 


