Specifications
Type:
Long Range Two-Way Remote Control System
Band:
Europe: 868 MHz SRD Band
America: 915 MHz ISM Band
RF power
Radio Signal &
Telemetry downlink:
Micro TX: Selectable 25mW and 100mW (250mW with FW 2.40 or later)
Standard TX: Selectable 10mW to 500mW, additional 1W and 2W available
with external power connected via XT30 socket
Diversity, Micro and Nano RX: 40mW
Receiver sensitivity:
Up to -130dBm
Antenna:
TX: 1x omnidirectional dipole antenna
RX: 2x omnidirectional dipole antennas, flexible antenna (Micro and Nano
RX)
R/C Channels:
8 (Diversity)/ 4(6) (Micro/Nano RX) PWM (freely mappable ) or up to
12-channel PPM stream outputs, standard 2.54mm servo connectors
Radio compatibility:
Any radio with PPM stream output ( absolute max. ratings: -0.3V - 15V )
JR Adapter for easy install on JR, FrSky and similar radios
Interface:
Micro TX: RGB LED light, push button, configuration via CRSF (TBS TANGO,
OpenTX ect. )
Standard TX: 1.3-inch OLED display and joystick for configuration, binding
and link stats, real-time telemetry link to any computer, tablet or phone and
Micro-USB for firmware upgrade
Recovery mode:
Diversity RX: Beacon-mode, receiver backup LiPo battery - operating time of
approx. 2 days
Failsafe:
Pre-set servo positions or stops outputting servo pulse - selectable in
configuration menu or via push button
Antenna connector:
Standard SMA (not RP-SMA)
Operating range:
Variable depending on output power and radio environment
Input power:
TX: +3.5 to 12.6V via RC or HT 3-pin input connector, External 2S to 3S LiPo
via XT30 connector (standard RX only)
RX: +4.5V to 8.4V
All reverse-polarity protected
Power consumption:
TX: 1.1W, at 25mW
TX: 3.2W, at 2000mW
Diversity RX: 1.5W / Micro/Nano RX: 1W
Ports:
Diversity RX: 1x BST (the CROSSFIRE RX does not power the BST line), 8x
Servo connectors - Micro RX: V1: 1x Servo, 1x BST / V2: 4x Servo, 1x BST -
Nano RX: 2x Pin-headers for 1x BST and 4x Servo
Working temperature:
0 - 40°C
Size:
Standard TX: 150 x 80 x 20 mm, Micro TX: 73 x 56 x 35 mm
Diversity RX: 30 x 50 x 12 mm, Micro RX: 40 x 14 x 9.5mm
Weight:
Micro TX: 38 grams
Standard TX: 340 grams, Diversity RX: 25 grams, Micro RX: 3.2 grams
Kit contents:
1x TBS CROSSFIRE TX transceiver unit, 1x TBS CROSSFIRE RX transceiver unit,
1x JR-adapter module, 1x Futaba-cable, 1x JR-cable, 1x custom-cable, 1x XT30
cable, 1x Transmitter SMA antenna, 2x Receiver SMA antenna


