PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RTS
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, Serial RX, MAVLink
RX, CRSF RX
PWM Ch1 to 12, RSSI, LQ, RSSI/LQ, SBUS, n.i.SBUS, Serial
TX, MAVLink TX, CRSF TX, DSMX, SmartAudio
Output type Micro V2/ Nano rx
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ, SBUS, n.i.
SBUS, CRSF TX, MAVLink TX, SmartAudio, DSMX
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ, CRSF RX,
MAVLink RX
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ, CRSF RX,
MAVLink RX
PWM Ch1 bis 12, PPM, RSSI, LQ, RSSI/LQ, SBUS, n.i.
SBUS, CRSF TX, MAVLink TX, SmartAudio, DSMX
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, BST SDA
PWM Ch1 bis 12, RSSI, LQ, RSSI/LQ, BST SCL
Receiver SBUS output
The CROSSFIRE 8ch diversity receiver as well as the CROSSFIRE Micro and Nano RX support SBUS and
n.i.SBUS (non-inverted) respectively. The diversity receiver exposes this functionality on output port 8,
selectable via the output port mapping menu. The Micro RX V1 only has one output port, and it is either
PWM, PPM, SBUS, n.i.SBUS or CRSF capable. The micro receiver v2 got 4 (6)outputs where you can choose
more than one output.
Receiver RSSI or/and LQ output
To get digital (PWM) RSSI, LQ (Link Quality) or RSSI/LQ output for use on OSD and similar equipment, pick a
free channel and set the output to signal type you need. You can also output one of those signals by
injecting it into the PPM stream for processing on an OSD or FC. Use the “Channel Map” menu for this.
Beside of RSSI the receiver can also output link quality (LQ) or a combined value (RSSI/LQ). The RSSI/LQ
value will always show the worse value of both. This is mostly useful if the used OSD only has one input for
link statistics. You can set up your warning levels in your osd as following:
