TC Electronic Finalizer Service Manual

__________________________________________________________________________________________________________________________________________________________________________________________________
TC Electronic A/S Finalizer Service manual page 16
Test Point Values, continued..:
TP Value Pos. Page Name Conditions/comments
20 1,9Vpp, 0VDC M3 7 Left input gain. Running Built-in Test program, Option: analog
21 1,9Vpp, 0VDC N2 7 Right input gain. Running Built-in Test program, Option: analog
22 +2,4VDC and 2.7Vpp M4 8 Left DA-output. Running Built-in Test program, Option: analog
23 +2,4VDC and 2.7Vpp M4 8 Right DA-output. Running Built-in Test program, Option: analog
24 10Vpp, max. 10mVDC L3 8 Left output amp Running Built-in Test program, Option: analog
25 10Vpp, max. 10mVDC L3 8 Right output amp Running Built-in Test program, Option: analog
26 -3.1VDC M3 6 GAIN-GND
27 +3.1VDC M3 6
L
out
10Vpp, balanced, max. 10mVDC,
THD+N: <0.01%
L1 6 Left output connector Running Built-in Test program, Option: analog
R
out
10Vpp, balanced, max. 10mVDC
THD+N: <0.01%
K1 6 Right output connector Running Built-in Test program, Option: analog
