TC Electronic Finalizer User Manual

26
MAIN PAGE Output
Analog
output level
(left and right)
Select
primary
output
Select no. of bits dithered to:
8 bit
16 bit (default for SPDIF)
18 bit
20 bit (default for analog out)
24 bit (default for AES)
FADE SECTION
CURVE sets the fade-out curve
TIME sets the fade-out time
FADE up/down/stop
LEVEL set fader level manually.
Note:
If an external fader is connected, all of the above
parameters are disabled.
Select the OUT section in the main page by pressing
the BLOCK keys
Primary Output
When selecting your primary output, the Finalizer automatically
selects a suitable dither.
If you select ANALOG, the Finalizer dithers to 20 bit
(the D to A converters are 20 bit).
If you select S/PDIF, the Finalizer dithers to 16 bit.
If you select AES/EBU, the dither is off, meaning that 24 bit raw
data is sent out of the Finalizer digital outputs.
Note: There is always signal present on both analog and digital
outputs.
Dither
With the dither parameter you can select the desired dither type
yourself. Select between: 8, 16, 18, 20, 22, 24 (off).
Note: The dither parameter is always reset when changing the
primary output.
Analog
Use the output bar for adjusting the analog output gain.
Range: -16 dB to +6 dB
Auto Fade
The Finalizer is capable of auto-fades up to 60 seconds.
Select the fade curve and the fade time.
To start the fade, select the fade up/down parameter and turn the
ADJUST wheel.
You also have the possibility of a manual fade, simply by select-
ing the LEV parameter and turning the ADJUST wheel.
The manual fade function can also be controlled by the TC
Master Fader.
Note: The pedal function in the Utility menu must be set to Fader
for external control.

TC Electronic Finalizer Specifications

General

Bit Depth	24-bit
Type	Mastering Processor
Inputs	Analog XLR, Digital AES/EBU, S/PDIF
Outputs	Analog XLR, Digital AES/EBU, S/PDIF
Processing	EQ, Compression, Limiting, Stereo Enhance
Sample Rate	32 kHz, 44.1 kHz, 48 kHz
