TC Electronic Finalizer User Manual

37
TECHNICAL SPECIFICATIONS
Analog Input
Connectors: XLR balanced (pin 2 hot)
Impedance: 15 kOhm
Max. Input Level: +22 dBu
Sensitivity: @ 12 dB headroom: -22 dBu to 10 dBu
A to D Conversion: 20 bit (4 bit, 64 times oversampling)
Dynamic Range: > 105 dB
THD: < 0.003% @ 1 kHz, +10 dB
Frequency Response: 10 Hz - 20 kHz: +0/-0.2 dB
Crosstalk: -60 dB max, 10 Hz to 20 kHz
Analog Output
Connectors: XLR balanced (pin 2 hot)
Impedance: 100 Ohm (active transformer)
Max Output Level: +22 dBu
Output Gain Range: 0 to -32 dB
D to A Conversion: 20 bit (1 bit 128 times oversampling)
Dynamic Range: > 96 dB
THD: < 0.008% @ 1 kHz, +10 dB
Frequency Response: 10 Hz - 20 kHz: +0/-0.3 dB
Crosstalk: -60 dB max, 10 Hz to 20 kHz
Digital Inputs and Outputs
AES/EBU In/Out: XLR
S/PDIF In/Out: Coaxial, RCA Type
Formats: EIAJ CP-340, IEC 958, S/PDIF (20 bit)
AES/EBU (24 bit)
Sample Rates: 32 kHz, 44.1 kHz and 48 kHz
PC-CARD Interface
Connector: Type 1 PC Cards
Standards: PC-CARD 2.0, JEIDA 4.0
Card Format: Supports up to 2 MB SRAM
Control Interface
MIDI: In/Out/Thru: 5 Pin DIN
Pedal: 1/4 inch phone jack
General
Finish: Black anodized aluminum face plate
Painted and plated steel chassis
Dimensions: 19” x 1.75” x 8.2” (485 x 45 x 195 mm)
Weight: 5.2 lbs (2.35 kg)
AC Power: 90 - 240 VAC without switch settings
3 Pin IEC power connector
Battery Life: >10 years
Radio Frequency Immunity/Interference
RFI/ESD: Conforms to FCC Class B,
EN55103-1 (CE), EN55103-2 (CE)
Environment
Operating Temperature: 32
O
F to 122
O
F (0
O
C to 50
O
C)
Storage Temperature: -22
O
F 167
O
F (-30
O
C to 70
O
C)
Humidity: Max. 95% non-condensing
All specifications are subject to change without notice.

TC Electronic Finalizer Specifications

General

Bit Depth	24-bit
Type	Mastering Processor
Inputs	Analog XLR, Digital AES/EBU, S/PDIF
Outputs	Analog XLR, Digital AES/EBU, S/PDIF
Processing	EQ, Compression, Limiting, Stereo Enhance
Sample Rate	32 kHz, 44.1 kHz, 48 kHz
