TC Electronic SYSTEM 6000 MKII User Manual

10
TC ICOn
Screen
The TC Icon screen is a touch-sensitive capacitive screen.
The resolution is 640 x 480 16 bit color resolution. The
touch calibration as well as brightness and colors can be
adjusted/selected in the TC Icon Setup menu.
Maintenance
The touch screen must be cleaned only with a soft cloth
slightly moistened with water or a mild detergent solution.
Do not spray liquids directly on the screen.
Faders
The Faders are touch-sensitive. The sensitivity of the
Faders can be adjusted so response to movement is
achieved only when operated with your finger-tips.
This way unintended movement of the Faders with e.g. a
sleeve etc. will not result in changes in parameter values.
The sensitivity can be adjusted in the TC Icon Setup menu.
TC Connection Cable.
8VHWKHVSHFLDO7&,FRQFDEOHVXSSOLHGZLWKWKHXQLW21/<
No other cables can be used. The 7.5 meters (22 feet)
cable cannot be extended as this will reduce the power for
WKH,FRQVXSSOLHGYLDWKHFDEOH
Mic stand mounting
7KHUHDUHWZRVWDQGDUGWKUHDGV´DQG´7KH7&,FRQ
can be mounted on both types without further accessories.
Mounting of plate.
Mount the supplied plate on the rear of the TC Icon, to
assure stable operation when placed on a table or similar.
This is easily done using the 4 screws and screwdriver
supplied with the unit.
Dimensions
D: 279mm
W: 198mm
H front: 33mm
TC Icon Front TC Icon Rear
198 mm
279 mm
