paGe Headframe sysTem - maIn
Bank Mode
7KH%DQNPRGHVHWWLQJVGHWHUPLQHWKHGHVWLQDWLRQEDQN
of the received program change on the specified MIDI
channels.
Normal mode:
This mode requires that the external sending MIDI device
can send both Controller 0 and 32 in addition to MIDI
program changes. This is an essential feature to recall
presets from a device holding more than 128 preset
location. (see table in next column for details)
Factory and User mode:
These modes will force any incoming program change
to access either Factory or User banks directly and are
typically used if your sending MIDI device cannot send
Controllers 0 and 32 as described above.
Normal mode
In Normal mode all banks can be accessed for program
FKDQJHV%DQNVHOHFWLRQLVGRQHYLD&WUO06%DQG
&WUO/6%
 &RQWUROOHUPXVWEHVHWWRLQDOOFDVHV
 &RQWUROOHUYDOXHPXVWPDWFKWKHEDQNQXPEHU\RX
wish to address according to the table below.
Ctrl 32 value 0 - F1: Reverb A (Music Stereo)
&WUOYDOXH  ) 5HYHUE%0XVLF6WHUHR
Ctrl 32 value 2 - F3: Reverb (Music Surround)
Ctrl 32 value 3 - F4: Reserved
Ctrl 32 value 4 - F5: Reverb A (Film Stereo)
&WUOYDOXH  ) 5HYHUE%)LOP6WHUHR
Ctrl 32 value 6 - F7: Reserved
Ctrl 32 value 7 - F8: Reverb (Film Surround)
Ctrl 32 value 8 - F9: Reserved
Ctrl 32 value 9 - F10: Mastering
Ctrl 32 value 10 - F11: Reserved
Ctrl 32 value 11 - F12: Pitch & Delay
Ctrl 32 value 12 - F13: Reserved
Ctrl 32 value 13 - F14: M5000 Presets
Ctrl 32 value 32 - User bank
&WUOYDOXH   &DUG%DQN
&WUOYDOXH   &DUG%DQN
&WUOYDOXH   &DUG%DQN
- - - - -
&WUOYDOXH   &DUG%DQN
Example:
<RXZLVKWRUHFDOOSUHVHWIURPWKH5HYHUE0XVLF
Surround) bank. According to the table above:
 6HW&WUOWR³´DQG&WUOWR³´DQGVHQGSURJUDP
change no 10.
SysEx Device ID
Range: 0 to 126
Select SysEx ID for the Mainframe.
MIDI Setup Page
Introduction
MIDI Channels
To recall presets for Scene, Routing and Engines 1 to 4
you must first setup individual MIDI channels for these
categories.
In the example above we have setup MIDI channels 1 to 4
for Engines 1 to 4 respectively; channel 5 to access Scene
presets and channel 6 to access Routing presets.
SMPTE
Basic Operation
 3UHVVSDUDPHWHUWRVHOHFWDQGXVH)DGHUWRVHWYDOXH
Reader Enabled
On/Off switch for the System 6000 SMPTE Reader.
Frame Rate
Range: 24 FPS, 25 FPS, 29.97 FPS,
30 Drop FPS, 30 FPS.
Running Status
The small field in the top left corner of the numeric display
ZLOOVWDWH³5XQQLQJ´ZKHQ6037(FORFNLVUXQQLQJ
