TCL 32S5400AF User Manual

TCL 32S5400AF
19 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #11 background imageLoading...
Page #11 background image
11
Basic TV Operations
1. Press
on the remote control to display the
homepage, Press Up/Down/Left/Right to select
(Settings) > Device Preferences > Quick start
> Enable quick start
and press OK to toggle
between on and off
.
2. Press
to return to previous interface.
Using TV Settings Menu
Allows you to adjust TV settings, such as picture and
sound.
1. Press
on the remote control to display the TV
settings menu.
2. Press Up/Down to select the desired item, then
press OK/Right to enter the corresponding submenu.
3. In submenus, press Up/Down to select menu
options, then press OK/Right to enter the option list
or the corresponding submenu, or press OK to toggle
on or off, or press Left/Right to adjust the setting.
4. Press
to return to the previous menu.
Note:You can also press
o
n the remote control, se-
lect TV settings (if available) and press OK to enter the
TV settings menu. Some options may not be available
for certain signal sources.
Accessing TCL Channel
Allows you to enjoy more VOD(Video on Demand)
contents or featured applications.
1. Press
on the remote control to enter TCL
Channel, or access through the TCL Channel icon
on homepage.
2. Press
to return to the previous menu.
Note: UI layout of TCL Channel will vary according
to models or countries.
Using Advanced System Settings Menu
Allows you to not only adjust device settings, such as
Network & Internet, Accounts & Sign-In and Apps, etc.,
but also set preferences.
1. Press
on the remote control to display the Smart
TV homepage.
2. Press Up/Right to move the cursor to
(Settings)
on the right top of the screen and press OK to enter
the advanced system settings.
3. Press Up/Down to choose the items and press OK
to enter.
4. Press
to return to previous interface.
Using Quick Start Function
It enables you to turn on your TV faster from standby
mode than turning this function off, but it will also
increase standby power consumption.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 32S5400AF and is the answer not in the manual?

TCL 32S5400AF Specifications

General IconGeneral
AC input voltage220-240 V
AC input frequency50/60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.5 W
Power consumption (typical)- W
Screen shapeFlat
LED backlightYes
Response time6.5 ms
Display diagonal32 \
Display brightness220 cd/m²
Display technologyLED
Native aspect ratio16:9
Native refresh rate60 Hz
Peak luminance ratio70 %
LED backlighting typeDirect-LED
Contrast ratio (typical)3000:1
Display diagonal (metric)80 cm
Motion interpolation technologyPPI (Picture Performance Index) 700
USB recordingNo
Processor cores4
Audio formats supportedMP3, WMA
Image formats supportedBMP, JPG, PNG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, OGM, TS, VP9, WMV
Picture processing technologyTCL IPQ 2.0 Engine
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
Music appsSpotify
Video appsAmazon Prime Video, Google TV, HBO, Hulu+, Netflix, Rakuten TV, Twitch, YouTube
Smart modesSports
Sports appsRed Bull TV
Operating system version11.0
App distribution platformGoogle Play
Operating system installedAndroid
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Audio decodersDolby Digital, Dolby Digital Plus
RMS rated power10 W
Number of speakers2
Audio output channels2.0 channels
Control typeButtons, Wireless
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
ProcessorMT5867 / 4x CA55
Internal memory2800 MB
Cord length1.5 m
User memory2100 GB
Warranty period2 year(s)
Processor frequency1.5 GHz
Color nameDark silver
Stand typeLegs stand
Product colorSilver
Heavy metals freeCd (cadmium)
Panel mounting interface100 x 100 mm
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version5.0
Bluetooth profilesA2DP, HID, SBC
Cables includedAC
Remote control typeRC902V
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-S2, DVB-T2, ISDB-C
HDCP version2.2
HDMI version1.4
RF connector typeF, IEC
USB 2.0 ports quantity1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Package depth125 mm
Package width800 mm
Package height506 mm
Package weight5000 g
Pallet width1200 mm
Pallet height1152 mm
Quantity per truck1188 pc(s)
Quantity per pallet18 pc(s)
Number of pallets per truck66 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)180 mm
Width (with stand)716 mm
Height (with stand)467 mm
Weight (with stand)3400 g
Depth (without stand)77 mm
Height (without stand)424 mm
Weight (without stand)3300 g
