Page #14 background imageLoading...
Page #14 background image
14
Using more of your TV
Note:
button on the remote control.
HDR Playback
Your TV supports HDR (High Dynamic Range) up to a
resolution of 1920 x 1080. HDR can be experienced with
resolution via USB and streaming, and with compatible
HDMI 1.4a devices.
Password in Parental Control
- The default password is 1234. You can change it to a
new one.
- The super password is 0423. If you forget your code,
enter the super password to override any existing
codes.
deselect. A checkmark will appear to the right of
the type when selected.
- Custom Schedule: Press Up/Down to select a
program, then press the RED button to set the
schedule, press OK to enter Schedule reminder.
- Select Date: Press the GREEN button to select
date.
- Reminders: Press the YELLOW button to view
your schedule list.
Note: T
o access the color buttons, you need to press
button on the remote control to display the virtual remote
control
3. Press to exit EPG.
Bluetooth Function
Bluetooth
®
is a wireless technology standard for
exchanging data over short distance between Bluetooth
devices. You can connect Bluetooth audio device,
mouse or keyboard via the TV.
1. Press
on the remote control to display the
homepage,
press Up/Right to select
(Settings)
>
Remotes & Accessories and press OK to enter.
2. Select Add accessory and press OK to enter.
The TV will search nearby Bluetooth devices
automatically.
3. Select an available device, press OK and follow the
guides on the screen to connect it.
Note: Bluetooth technology (if available in your TV) uses
2.4GHz frequency thus close proximity to WiFi access
points, routers or microwave ovens might interfere with
Bluetooth audio streaming. If you face interruptions
in audio reception, you should restart your Bluetooth
you continue to face issues you should move closer
to TV or increase space between TV and source of
interferences.
The Bluetooth
®
word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any use
of such marks by TTE Corporation is under license.
Other trademarks and trade names are those of their
respective owners.
Freeview
Never miss a thing with freeview!
Find out what’s on now, next or over the next 7 days with
the easy to use TV guide.
Looking for your favourite show? Use Search for quick
access to all your favourite on demand from ABC iview,
SBS On Demand, 7+, 9Now and 10 Play.
All in one place, all for free.
Settings
countries.Unlimited membership is required. More

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 32S5400AF and is the answer not in the manual?

TCL 32S5400AF Specifications

General IconGeneral
AC input voltage220-240 V
AC input frequency50/60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.5 W
Power consumption (typical)- W
Screen shapeFlat
LED backlightYes
Response time6.5 ms
Display diagonal32 \
Display brightness220 cd/m²
Display technologyLED
Native aspect ratio16:9
Native refresh rate60 Hz
Peak luminance ratio70 %
LED backlighting typeDirect-LED
Contrast ratio (typical)3000:1
Display diagonal (metric)80 cm
Motion interpolation technologyPPI (Picture Performance Index) 700
USB recordingNo
Processor cores4
Audio formats supportedMP3, WMA
Image formats supportedBMP, JPG, PNG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, OGM, TS, VP9, WMV
Picture processing technologyTCL IPQ 2.0 Engine
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
Music appsSpotify
Video appsAmazon Prime Video, Google TV, HBO, Hulu+, Netflix, Rakuten TV, Twitch, YouTube
Smart modesSports
Sports appsRed Bull TV
Operating system version11.0
App distribution platformGoogle Play
Operating system installedAndroid
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Audio decodersDolby Digital, Dolby Digital Plus
RMS rated power10 W
Number of speakers2
Audio output channels2.0 channels
Control typeButtons, Wireless
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
ProcessorMT5867 / 4x CA55
Internal memory2800 MB
Cord length1.5 m
User memory2100 GB
Warranty period2 year(s)
Processor frequency1.5 GHz
Color nameDark silver
Stand typeLegs stand
Product colorSilver
Heavy metals freeCd (cadmium)
Panel mounting interface100 x 100 mm
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version5.0
Bluetooth profilesA2DP, HID, SBC
Cables includedAC
Remote control typeRC902V
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-S2, DVB-T2, ISDB-C
HDCP version2.2
HDMI version1.4
RF connector typeF, IEC
USB 2.0 ports quantity1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Package depth125 mm
Package width800 mm
Package height506 mm
Package weight5000 g
Pallet width1200 mm
Pallet height1152 mm
Quantity per truck1188 pc(s)
Quantity per pallet18 pc(s)
Number of pallets per truck66 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)180 mm
Width (with stand)716 mm
Height (with stand)467 mm
Weight (with stand)3400 g
Depth (without stand)77 mm
Height (without stand)424 mm
Weight (without stand)3300 g
