TCL 32S5400AF User Manual

4
Chapter 2 Connections and Setup
Initial Setup
Welcome wizard
appears, which guides you through the initial setup
your remote, connecting to the network, and more. During each step, either make a choice or skip the step. If you
skip a step, you can perform the setup later from the settings menu.
Note: When you pair your remote, keep the remote control and TV in 1 meter, and follow the on-screen guide for
pairing.
will be promted to pair the remote with the TV again when you use the Google
TV Buttons
- Power button
If the batteries in your remote control are run down, you can use the button on your TV set.
The model has only one
button. It may work just as Standby/Quit standby button, or as a multi-function
controller.
You can turn on the TV by pressing the
button at the bottom left of the TV back case.
While the TV is on, press the
button to display the multi-function menu. For more information about how to use
the multi-function menu, please refer to the figure below.
CH+ CH- Volume+ Source OKVolume-
Standby
Tips: Short click to change, long click to select.
• Press to move the highlight to the next function selection
•
Note:
You can follow the on-screen guide to operate. Figures and illustrations are provided for reference only and may
vary depending on the model.

TCL 32S5400AF Specifications

General

AC input voltage	220-240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
Screen shape	Flat
LED backlight	Yes
Response time	6.5 ms
Display diagonal	32 \
Display brightness	220 cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
Peak luminance ratio	70 %
LED backlighting type	Direct-LED
Contrast ratio (typical)	3000:1
Display diagonal (metric)	80 cm
Motion interpolation technology	PPI (Picture Performance Index) 700
USB recording	No
Processor cores	4
Audio formats supported	MP3, WMA
Image formats supported	BMP, JPG, PNG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, OGM, TS, VP9, WMV
Picture processing technology	TCL IPQ 2.0 Engine
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
Music apps	Spotify
Video apps	Amazon Prime Video, Google TV, HBO, Hulu+, Netflix, Rakuten TV, Twitch, YouTube
Smart modes	Sports
Sports apps	Red Bull TV
Operating system version	11.0
App distribution platform	Google Play
Operating system installed	Android
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.2
Audio decoders	Dolby Digital, Dolby Digital Plus
RMS rated power	10 W
Number of speakers	2
Audio output channels	2.0 channels
Control type	Buttons, Wireless
Programming period	8 day(s)
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Processor	MT5867 / 4x CA55
Internal memory	2800 MB
Cord length	1.5 m
User memory	2100 GB
Warranty period	2 year(s)
Processor frequency	1.5 GHz
Color name	Dark silver
Stand type	Legs stand
Product color	Silver
Heavy metals free	Cd (cadmium)
Panel mounting interface	100 x 100 mm
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Bluetooth profiles	A2DP, HID, SBC
Cables included	AC
Remote control type	RC902V
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-S2, DVB-T2, ISDB-C
HDCP version	2.2
HDMI version	1.4
RF connector type	F, IEC
USB 2.0 ports quantity	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Package depth	125 mm
Package width	800 mm
Package height	506 mm
Package weight	5000 g
Pallet width	1200 mm
Pallet height	1152 mm
Quantity per truck	1188 pc(s)
Quantity per pallet	18 pc(s)
Number of pallets per truck	66 pc(s)

Weight and Dimensions

Depth (with stand)	180 mm
Width (with stand)	716 mm
Height (with stand)	467 mm
Weight (with stand)	3400 g
Depth (without stand)	77 mm
Height (without stand)	424 mm
Weight (without stand)	3300 g
