12
Chapter 4 Using more of your TV
Enabling Subtitle Languages on Digital TV Channels
1. Press
on the remote control, select Channels >
Subtitle > Digital Subtitle Language 1st and press
OK/Right to enter.
2. Press Up/Down to select a subtitle language as your
preferred language and press OK
3. Press Up/Down to select Digital Subtitle Language
2nd and press OK/Right to enter.
4. Press Up/Down to select a secondary subtitle
language and press OK
5. Press to return to previous interface.
Selecting a Subtitle Type on Digital TV Channels
1. Press
on the remote control, select Channels >
Subtitle > Subtitle Type and press OK/Right to
enter.
2. Press Up/Down to select a subtitle type and press
OK Hearing Impaired
to display the hearing impaired subtitles with your
selected language.
3. Press
to return to previous interface.
Using Teletext
Selecting Decoding Page Language
1. Press
on the remote control, select Channels >
Teletext > Decoding Page Language and press
OK/Right to enter.
2. Press Up/Down to select a proper type of language
in which Teletext will display and press OK to
3. Press to return to previous interface.
Digital Teletext Language
On digital TV channels, depending on the broadcaster,
you may be able to enjoy a service with multiple initial
Teletext pages in different languages. This function
allows you to select an available language as primary
language, which relates to different initial Teletext
pages.
1. Press
on the remote control, select Channels >
Teletext > Digital Teletext Language and press
OK/Right to enter.
2. Press Up/Down to select a language and press OK
3. Press to return to previous interface.
Network Wake Up
This function allows you to turn on your TV from standby
mode via a network. To use this function, please make
sure:
1. Your TV is connected to an effective home network;
2. The desired controller, such as a smartphone, is
connected to the same network as your TV;
3. An app which supports network waking up function,
has been installed into the controller;
4. Networked standby is set to on in the Network &
Internet menu under homepage. Press
, select
(Settings) > Network & Internet, use Down to
Installing Channels
This section describes how to search and store
channels automatically. This may be done in either of
the cases below:
- you are prompted that there are no channels in TV
mode;
- you want to update your channels.
1. In TV mode, press
on the remote control and
select Channels > Channel scan. Press OK/Right
to enter.
2. The TV installs and arranges channels according
to your country or region. Press Up/Down to select
Country/Region, and press OK/Right to enter.
Enter the default password 1234 or your own
password in case you have changed the password
in the System > Parental Controls menu. Press
Up/Down to select your country or region and press
OK to confirm.
3. Press Up/Down to select Scan Automatically and
press OK/Right to enter.
4. Press Up/Down to select Channel Type and
press Left
/Right to select Digital, Analog or
Digital&Analog.
5. After configuration is completed, press Down to
select Search and press OK to start scanning
channels.
6. The channel search may take a few minutes. After
the automatic search, channels are arranged in a
preset order. If you wish to hide or move channels,
press
on the remote control, select Channels >
Channel Organizer and press OK/Right to enter.
Note: If the channel search retrieved only the analogue
channels it could be caused by poor broadcasting and
therefore is not covered by manufacturer warranty.
Manufacturers cannot be held responsible for lack of or
poor broadcasting in some areas.
Using Subtitles
You can enable subtitles for each TV channel. Subtitles
are broadcast via Teletext or DVB-T digital broadcasts.
With digital broadcasts, you have the additional option
of selecting a preferred subtitle language.
Notes:
- Subtitle can also be enabled by pressing
button on
the remote control to display the virtual remote control
keyboard and select Subtitle directly.
- Some options are available only when Subtitle is set
to on.
Turning On/Off Subtitles
1. Press
on the remote control, select Channels >
Subtitle and press
OK/Right
to enter.
2. Select the Subtitle option, press OK to toggle
between on and off.
3. Press
to return to previous interface
.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TCL 32S5400AF and is the answer not in the manual?

TCL 32S5400AF Specifications

General IconGeneral
AC input voltage220-240 V
AC input frequency50/60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.5 W
Power consumption (typical)- W
Screen shapeFlat
LED backlightYes
Response time6.5 ms
Display diagonal32 \
Display brightness220 cd/m²
Display technologyLED
Native aspect ratio16:9
Native refresh rate60 Hz
Peak luminance ratio70 %
LED backlighting typeDirect-LED
Contrast ratio (typical)3000:1
Display diagonal (metric)80 cm
Motion interpolation technologyPPI (Picture Performance Index) 700
USB recordingNo
Processor cores4
Audio formats supportedMP3, WMA
Image formats supportedBMP, JPG, PNG
Video formats supportedAVI, H.264, H.265, MKV, MP4, MPG, OGM, TS, VP9, WMV
Picture processing technologyTCL IPQ 2.0 Engine
High Dynamic Range (HDR) technologyHigh Dynamic Range 10 (HDR10)
Music appsSpotify
Video appsAmazon Prime Video, Google TV, HBO, Hulu+, Netflix, Rakuten TV, Twitch, YouTube
Smart modesSports
Sports appsRed Bull TV
Operating system version11.0
App distribution platformGoogle Play
Operating system installedAndroid
Hybrid Broadcast Broadband TV (HbbTV) version2.0.2
Audio decodersDolby Digital, Dolby Digital Plus
RMS rated power10 W
Number of speakers2
Audio output channels2.0 channels
Control typeButtons, Wireless
Programming period8 day(s)
Number of OSD languages29
Firmware upgradeable viaNetwork, USB
On Screen Display (OSD) languagesALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
ProcessorMT5867 / 4x CA55
Internal memory2800 MB
Cord length1.5 m
User memory2100 GB
Warranty period2 year(s)
Processor frequency1.5 GHz
Color nameDark silver
Stand typeLegs stand
Product colorSilver
Heavy metals freeCd (cadmium)
Panel mounting interface100 x 100 mm
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version5.0
Bluetooth profilesA2DP, HID, SBC
Cables includedAC
Remote control typeRC902V
Tuner typeAnalog & digital
Analog signal format systemNTSC, PAL, SECAM
Digital signal format systemDVB-S2, DVB-T2, ISDB-C
HDCP version2.2
HDMI version1.4
RF connector typeF, IEC
USB 2.0 ports quantity1
Consumer Electronics Control (CEC)T-link
Common interface Plus (CI+) version1.3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Package depth125 mm
Package width800 mm
Package height506 mm
Package weight5000 g
Pallet width1200 mm
Pallet height1152 mm
Quantity per truck1188 pc(s)
Quantity per pallet18 pc(s)
Number of pallets per truck66 pc(s)
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)180 mm
Width (with stand)716 mm
Height (with stand)467 mm
Weight (with stand)3400 g
Depth (without stand)77 mm
Height (without stand)424 mm
Weight (without stand)3300 g
