TCL 32S5400AF User Manual

8
Connecting to a Wireless Network
To connect to a wireless network
1. Ensure you have:
• A router broadcasting a high-speed wireless signal
• A high-speed internet connection
2.
Use the Network & Internet menu
Network Connection
Your TV will require an internet connection to operate all functions. Data usage charges may apply.
Please refer to your Internet Service Provider (ISP) for additional information.
To access the internet, you must subscribe to high speed broadband internet service from your internet service
provider.
Your TV can be connected to your home network in two ways:
• Wired, using the RJ45 (LAN) connector on the back panel.
• Wireless, using the internal wireless or external wireless USB adapter and your home wireless network.
Note: The following instructions are just the usual ways to connect your TV to the wired or wireless network. The
your home network, please refer to your ISP(Internet Service Provider).
Connecting to a wired Network
To connect to a wired network:
1. Ensure you have:
• An Ethernet cable long enough to reach your TV
• A router or modem with an available Ethernet port
• A high-speed internet connection
• An Ethernet (LAN) port on the back of the TV
2. Connect your Ethernet cable to the router and to the
Ethernet port on the back of the TV.
3. Use the Network & Internet menu
Connections and Setup
Router
Modem Internet
LAN port
Modem Internet
Wireless router
Note: Please follow below steps to enter the Network & Internet menu.
1. Press
on the remote control. The Smart TV homepage is displayed.
2.
Press Up/Right to move the cursor to
(Settings)
on the right top of the screen and press OK to enter.
3. Press
Up/Down
to select Network & Internet, then press OK to enter the submenu and follow the on-screen
guidance to set up your network.

TCL 32S5400AF Specifications

General

AC input voltage	220-240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	- W
Screen shape	Flat
LED backlight	Yes
Response time	6.5 ms
Display diagonal	32 \
Display brightness	220 cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	60 Hz
Peak luminance ratio	70 %
LED backlighting type	Direct-LED
Contrast ratio (typical)	3000:1
Display diagonal (metric)	80 cm
Motion interpolation technology	PPI (Picture Performance Index) 700
USB recording	No
Processor cores	4
Audio formats supported	MP3, WMA
Image formats supported	BMP, JPG, PNG
Video formats supported	AVI, H.264, H.265, MKV, MP4, MPG, OGM, TS, VP9, WMV
Picture processing technology	TCL IPQ 2.0 Engine
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
Music apps	Spotify
Video apps	Amazon Prime Video, Google TV, HBO, Hulu+, Netflix, Rakuten TV, Twitch, YouTube
Smart modes	Sports
Sports apps	Red Bull TV
Operating system version	11.0
App distribution platform	Google Play
Operating system installed	Android
Hybrid Broadcast Broadband TV (HbbTV) version	2.0.2
Audio decoders	Dolby Digital, Dolby Digital Plus
RMS rated power	10 W
Number of speakers	2
Audio output channels	2.0 channels
Control type	Buttons, Wireless
Programming period	8 day(s)
Number of OSD languages	29
Firmware upgradeable via	Network, USB
On Screen Display (OSD) languages	ALB, BUL, CRO, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, MAC, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, TUR, UKR
Processor	MT5867 / 4x CA55
Internal memory	2800 MB
Cord length	1.5 m
User memory	2100 GB
Warranty period	2 year(s)
Processor frequency	1.5 GHz
Color name	Dark silver
Stand type	Legs stand
Product color	Silver
Heavy metals free	Cd (cadmium)
Panel mounting interface	100 x 100 mm
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	5.0
Bluetooth profiles	A2DP, HID, SBC
Cables included	AC
Remote control type	RC902V
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-S2, DVB-T2, ISDB-C
HDCP version	2.2
HDMI version	1.4
RF connector type	F, IEC
USB 2.0 ports quantity	1
Consumer Electronics Control (CEC)	T-link
Common interface Plus (CI+) version	1.3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Package depth	125 mm
Package width	800 mm
Package height	506 mm
Package weight	5000 g
Pallet width	1200 mm
Pallet height	1152 mm
Quantity per truck	1188 pc(s)
Quantity per pallet	18 pc(s)
Number of pallets per truck	66 pc(s)

Weight and Dimensions

Depth (with stand)	180 mm
Width (with stand)	716 mm
Height (with stand)	467 mm
Weight (with stand)	3400 g
Depth (without stand)	77 mm
Height (without stand)	424 mm
Weight (without stand)	3300 g
