• Under-Voltage limit setting and read back.
• Power-supply start up mode (last setting or safe mode).
1.2.4 Analog Voltage Programming and Monitoring
Analog inputs and outputs are provided at the rear panel for analog control of the power supply. The
output voltage and the current limit can be programmed by analog voltage or by resistor,
and can
be monitored by analog voltage. The power supply output can be remotely set to On or Off and
analog signals monitor the proper operation of the power supply and the mode of
operation
(CV/CC).
1.2.5 Parallel Operation
Up to four ™ Series power supplies of the same output voltage and current rating can be
paralleled
in master-slave configuration with automatic current sharing to increase available power.
1.2.6 Output Connections
Output connections are made to rear panel Connector. Either the positive or negative terminal may
be grounded or the output may be floated. Models up to 100VDC rated output shall not float outputs
more than +/- 200VDC above/below chassis ground. Models up to 600VDC rated output shall not
float outputs more than +/- 600VDC above/below chassis ground. Contact factory for assistance with
higher float voltage applications. Local or remote sense may be used.
1.2.7 Cooling and Mechanical Construction
The ™ Series is cooled by an internal fan. At installation, care must be taken to allow free air
flow into the power supply via the front panel, and out of the power supply via the rear panel.
1.3 Accessories
1.3.1 Accessories provided with the power supply
1.3.1.1 Input connector protection, includes 3 parts:
• Strain relief bracket assembly.
• Strain relief P/N: 5301 5440 (LAPP GROUP).
• Lock nut P/N: 8216 (AGRO).
1.3.1.2 AC Input Plug P/N: PC 5/ 4-STCL1-7, 62 (Phoenix contact)
1.3.1.3 Output connector/ Bus bars protection
• Output protection assembly.
• Output Plug P/N: PC 5/ 4-STCL1-7, 62 (Phoenix contact), for output voltage including and above
150VDC.Serial Link Cable
1.3.1.4 Serial link cable
Serial link cable, for linking power supplies by RS485 communication.
Cable description: 0.5m length, shielded, RJ-45 type plugs, 8 contacts (P/N: GEN/RJ45).
