1.3.1.5 Misc. Hardware
• DB-26 Connector P/N: 10090769-P264ALF (FCI)
•
DB-15 Backshell P/N: 86303638BLF (FCI)
• CD-ROM
• SEMS Screw M3X6 Fe Ni, 2 Pcs.
• Flat head screw M3X8 Fe Ni, 2 Pcs.
1.3.1.6 Bus bars Screws kits
10V~40V Models
• Hex. Screw M10X25 St. St., Type DIN933, 4 Pcs.
• Hex. Nut M10 St. St., Type DIN493B, 4 Pcs.
• Flat washer M10 St. St., Type DIN125A, 8 Pcs.
• Spring washer M10 St. St., Type DIN127B, 4 Pcs.
60V~100V Models
• Hex. Screw M8X25 St. St., Type DIN933, 2 Pcs.
• Hex. Nut M8 St. St., Type DIN493B, 2 Pcs.
• Flat washer M8 St. St., Type DIN125A, 4 Pcs.
• Spring washer M8 St. St., Type DIN127A, 2 Pcs.
1.3.2 Optional accessories
1.3.2.1 Printed User Manuals
For ordering printed User manual, the P/N is: G/M
1.3.2.2 Serial Port Cables
• For ordering serial port cables refer to the User manual in the CD-ROM.
• USB/LAN cables are not provided with the power supply.
1.3.2.3 Paralleling Cable
• For ordering paralleling cables refer to the User manual in the CD-ROM.
1.3.2.4 AC Cables
AC Cables are not provided with the power supply. Refer to Table 1-1 for recommended AC
input cables (customer applied).
AC Input Range
AC Input Cable
190~240~, Three phase Min. 4 X 12AWG (Three wires plus Safety ground), stranded copper,
300V, 60°C minimum, 3m max. length, outer diameter 10~14mm.
380~480~, Three phase Min. 4 X 16AWG (Three wires plus Safety ground), stranded copper,
600V, 60°C minimum, 3m max. length, outer diameter 10~14mm.
Table 1-1: Recommended AC Input Cables
