1.2.4. Analog Voltage Programming and Monitoring
Analog inputs and outputs are provided at the rear panel for analog control of the power
supply. The output voltage and the current limit can be programmed by analog voltage or
by resistor, and can be monitored by analog voltage. The power supply output can be
remotely set to On or Off and analog signals monitor the proper operation of the power
supply and the mode of operation (CV/CC).
1.2.5. Parallel Operation
Genesys
TM
power supplies of the same output voltage and current rating can be paralleled
in master-slave configuration with automatic current sharing to increase power available.
1.2.6. Output Connections
Output connections are made to rear panel via bus-bars up to 300V. For greater than
300Vo via stud terminals. Either the positive or negative terminal may be grounded or the
output may be floated. Contact factory for assistance with higher float voltage applications.
Local or remote sense may be used. In remote sense, the voltage drop on the load wires
should be minimized. Refer to the specifications for the maximum voltage drop value.
1.2.7. Cooling and Mechanical Construction
The Genesys
TM
series is cooled by internal fans. At the installation, care must be taken to
allow free airflow into the power supply via the front panel and out of the power supply via
the rear panel.
CAUTION
Observe all torque guidelines within this manual. Over torqueing may damage
unit or accessories. Such damage is not covered under manufacturer’s warranty.
1.3. Accessories
1.3.1. Included Accessories - The following accessories are delivered with the power supply.
1.3.1.1. Serial Link Cable:
Serial linking cable linking power supplies by RS-485 communication (GEN/RJ45).
Cable description: 0.5m Length, shielded, RJ-45 type plugs, eight (8) contacts
(P/N 15507201)
1.3.1.2. Hardware:
Strain Relief for AC Cord
Output terminal Shield
DB25 Programming Plug kit (AMP 749809-9)
1.3.2. Optional Communication Cables
RS-232 Cables to connect GEN to Serial Port on PC
RS-485 Cable to connect GEN to Serial Port on PC
GEN to PC(DB9) GEN/485-9 P/N 15-507-202
1.3.3. AC cables – Not applicable.
GEN to PC (DB9) GEN 232/9 P/N 15-507-203
GEN 232/25 P/N 15-507-204
