2.4. PROTECTIVE FUNCTIONS
V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
1. OCP %
0100
2. OCP Type --- Constant current
3. Knee point protection --- None, No damage at knee point operation
4. Short circuit protection --- Yes
5. Short circuit burn-in --- Yes
6. Foldback protection --- Output shut down, manual reset by front panel OUT button.
7. Foldback response time S Less than 1
8. OVP Type --- Inverter shut-down, manual reset by On/Off recycle or by OUT button.
9. OVP programming accuracy % 5% Full Scale
10. OVP adjustment method --- Adjust by front panel Voltage encoder and comm. port.
11. OVP trip point V 0.05 to (1.02 -1.05) Rated Output Voltage
12. OVP response time mS Less than 10mS for Output to begin to drop.
13. Max. OVP reset time S 7 from Turn On
14. Output under voltage limit --- Preset by front panel or communication port. Prevents from adjusting V
out
below limit.
Raises the Output good signal in case of output voltage is below limit.
15. Input under voltage protection --- Yes. Power supply shut down below low line.
16. Over temp protection --- Unit shall shut down when internal temperature exceeds safe operating levels. (Latched in Safe mode and
unlatched in auto mode).
17. Phase Loss Protection Yes
2.5. DYNAMIC CHARACTERISTICS
V 7.5 10 12.5 20 25 30 40 50 60 80 100 125 150 200 250 300 400 500 600
1. Up-prog. Response time, 0Vomax
full-load
mS 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
2. Down-prog response time full-load mS 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100 100
3. Transient response time (cv mode)
mS
Time for the output voltage to recover within 2% of its rated output voltage for a load change of 50 100% or
100 50% of rated output set-point. Less than 3.
NOTE: Properties 5.1- 5.6 with Resistive Load.
4. Time for Output Stable S 2 maximum from enable output until output stable.
5. Output fall and rise --- Overshoot limited to 125% Rated Output. Voltage at No-Load, Full-Load, Resistive Load.
6. Start-up delay S Less thank 7 (without IEEE option)
2.6. REMOTE ANALOG CONTROL AND SIGNALS
1. Vout voltage programming ---
0 100%, 0 5V or 0 10V, user selectable. Accuracy & Linearity +/-1% of Rate Vo.
2. Iout voltage programming ---
0 100%, 0 5V or 0 10V, user selectable. Accuracy & Linearity +/-1% of Rate Io.
3. Vout resistor programming ---
0 100%, 0 5/10kohm full scale, user selectable. Accuracy & Linearity +/-1% of Rate Vo.
4. Iout resistor programming ---
0 100%, 0 5/10kohm full scale, user selectable. Accuracy & Linearity +/-1% of Rate Io.
5. On/Off control (rear panel) --- By voltage: 0.6V = Disable, 2-15V = enable (default) or dry contact, user selectable logic
6. Output current monitor ---
0 5V or 0 10V, accuracy 1%, user selectable
7. Output voltage monitor ---
0 5V or 0 10V, accuracy 1%, user selectable
8. Power supply OK signal --- Yes. TTL high-OK, 0V (500ohm impedance)-Fail
9. Parallel operation --- Up to Four (4) identical units may be connected in Master/Slave Mode with ‘Single’ wire connection.
In Advance parallel feature, the current of Master Unit, multiplied by number of units connected in parallel, is
made available on digital interface and displayed on front panel of Master unit. Remote analog current
monitor of the Master is scaled to output current of the Master unit (only).
10. Series operation --- Possible (with external diodes), up to identical 2 units with total output not to exceed +/-600V from chassis
ground.
11. CV/CC signal ---
CV: TTL high (4 5V) source: 10mA, CC: TTL low (0 4V): 10mA
12. Enable/Disable --- Dry contact. Open: off, Short on. Max. voltage at Enable/Disable Contacts 6V
13. Remote/Local selection ---
Selects Remote or Local operation by elect. Voltage: 0 0.6V/2 15V, <0.6V = Local 2-15V = Remote.
14. Remote/Local signal --- Signal operating mode in use.
