9.3. Isolated Programming & Monitoring Connector
Refer to Table 9-1 for detailed description of the rear panel Isolated Programming &
Monitoring connector. To provide the lowest noise performance, it is recommended to use
shielded-twisted pair wiring.
Refer to Fig.9-1 for description of the connector.
Isolated programming plug P/N: MC1.5/8-ST-3.81, Phoenix.
Table 9-1: Detailed Description of Isolated Programming & Monitoring Connector
Terminal Signal name Function
Range 0-5/0-10V
IS510 option
Range 4-20mA
IS420 option
1 SHLD
Shield, connected internally to chassis
of the supply.
Chassis ground
2 +VPROG_ISO Output voltage programming input 0-5/0-10V 4-20mA
3 +IPROG_ISO Output current programming input 0-5/0-10V 4-20mA
4 GND_ISO Ground for programming signals. Ground Ground
5 GND_ISO Ground for programming signals. Ground Ground
6 +VMON_ISO Output voltage monitoring output 0-5/0-10V 4-20mA
7 +IMON_ISO Output current monitoring output 0-5/0-10V 4-20mA
8 SHLD
Shield, connected internally to chassis
of the supply.
Chassis ground
1
2
3
4
5
6
7
8
Shield
+VPROG_ISO
+IPROG_ISO
GND_ISO
Shield
+IMON_ISO
+VMON_ISO
GND_ISO
Fig.
9
-
1: Isolated Programming & Monitoring connector
