1.4. Model Number Format
The model numbering system for Genesys
TM
power supply includes symbols for features and
options. They are separated by dashes.
The following chart explains the model number for the GEN Power Supply Family.
Option AC Input Volts Factory Specials
Note 5 Note 1,2,3 Note 4
IS510
ISOL PROG
0-5V, 0-10V
3P208
208VAC,3Φ 47 / 63Hz
IS420
ISOL PROG
4-20mA
3P400
400VAC,3Φ 47 / 63Hz
IEMD
IEEE W/
MULTI-DROP
3P480
480VAC,3Φ 47 / 63Hz
MD
STANDARD W/
MULTI-DROP
LAN
LXI CERTIFIED
ETHERNET OPTION
Blank for standard
supplies
Note 1: See Specifications for Input Range.
Note 2: CE Mark with IEMD to 400VDC Output, without IEMD to 600VDC
Note 3: All 3
are four wire input = 3
+ GND (No Neutral).
Note 4: Analog Meters are NOT available.
Note 5: IS510, IS420, IEMD, or LAN may not be installed together.
Factory Installed. Limit one (1) per Power Supply.
EXAMPLES: GEN10-1000-3P208
GEN10-1000-IEMD-3P400
GEN 10-1000-IEMD-3P400-1292
WARNING
IEEE 488/ RS232 Option
There is a potential shock hazard at the RS232/485/LAN and the IEEE
ports when using power supplies with rated or combined voltage greater
than 400V and the Positive Output of the Power Supply is grounded.
Do Not connect the Positive Output to ground when using the
RS232/485, LAN or IEEE.
DC OUTPUT
CURRENT
DC OUTPUT
VOLTAGE
GENXXXX—XXXX—XXXXX—XXXXX—XXXX
AC INPUT
VOLTS
OPTIONS
FACTORY
SPECIALS
