Table 4-2: Rear Panel Connections and Controls
Number Item Description
Section
1 AC input connector M6 Stud terminal suitable for ring lugs. 3.7
2 DC output Bus-bars up to 300V models.
Stud terminals for models above 300V.
Fig. 4.2
3 Remote-In
connector
RJ-45 type connector, use for connecting power supplies to RS232
or RS485 port of computer for remote control purposes. When using
several power supplies in a power system, the first unit Remote-In is
connected to the computer and the remaining units are chained,
Remote-In to Remote-Out.
8.3
8.4
4 Remote Out
connector
RJ-45 type connector, used for chaining power supplies to form a
serial communication bus.
8.3
8.4
5 J1 Analog Remote
connector
Connector for remote analog interface. Includes output voltage and
current limit programming and monitoring signals, Shut-off control
(electrical signal), Enable/Disable control (dry-contact), power
supply ok (PS_OK) signal and operation mode (CV/CC) signal.
4.4
6 SW1 Setup switch Nine position DIP switch for selecting remote programming and
monitoring modes for Output Voltage, Current Limit and other
control functions.
4.3
7 J2 Remote sense
connector
Connector for making remote sensing connections to the load for
regulation of the load voltage and compensation of load wire drop.
8 Blank or Option
Plate
Blank sub-plate for standard units.
Other plates and connectors for options such as Isolated Analog,
IEMD or LAN.
9 IEEE switch LAN
switch
Two position DIP switch for selecting option mode or RS232/485
mode. The options may be IEEE or LAN.
10 Ground screw M5x20mm screw for chassis ground connection.
