Table 8-6: Current programming range
Model
Minimum
(A)
Maximum
(A)
7.5-1000 0.0 1000.0
10-1000 0.0 1000.0
12.5-800 0.0 800.0
20-500 0.0 500.0
25-400 0.0 400.0
30-333 0.0 333.0
40-250 0.0 250.0
50-200 0.0 200.0
60-167 0.0 167.0
80-125 0.0 125.0
100-100 0.0 100.0
125-80 0.0 80.0
150-66 0.0 66.0
200-50 0.0 50.0
250-40 0.0 40.0
300-33 0.0 33.0
400-25 0.0 25.0
500-20 0.0 20.0
Table 8-7: OVP Programming Range Table 8-8: UVL Programming Range
Model
Rated Output Voltage
(V)
Minimum
(V)
Maximum
(V)
Model
Rated Output Voltage
(V)
Min
imum
(V)
Maximum
(V)
7.5-1000 0.75 8.25 7.5-1000 0 7.125
10-1000 1 11 10-1000 0 9.5
12.5-800 1.25 13.75 12.5-800 0 11.875
20-500 2 22 20-500 0 19
25-400 2.5 27.5 25-400 0 23.75
30-333 3 33 30-333 0 28.5
40-250 4 44 40-250 0 38
50-200 5 55 50-200 0 47.5
60-167 6 66 60-167 0 57
80-125 8 88 80-125 0 76
100-100 10 110 100-100 0 95
125-80 12.5 137.5 125-80 0 118.75
150-66 15 165 150-66 0 142.5
200-50 20 220 200-50 0 190
250-40 25 275 250-40 0 237.5
300-33 30 330 300-33 0 285
400-25 40 440 400-25 0 380
500-20 50 550 500-20 0 475
600-17 60 660 600-17 0 570
