A. Fault Enable Register (FENA nn, FENA?)
The Fault Enable Register is set to the enable faults SRQs.
Table 8-12: Fault Enable Register
BIT
Enable
bit name
Fault symbol Bit Set condition Bit reset condition
0 (LSB) Spare bit SPARE
1 AC Fail AC
2 Over Temperature OTP
3 Foldback FOLD
4 Over Voltage OVP
5 Shut Off SO
6 Output Off OFF
7(MSB) Enable ENA
User command:
“FENA nn” where nn is
hexadecimal
User command: “FENA nn” where
nn is hexadecimal (if nn=”00”, no
fault SRQs will be generated).
B. Fault Event Register (FEVE?)
The Fault Event will set a bit if a condition occurs and it is enabled. The register is
cleared when FEVE?, CLS or RST commands are received.
Table 8-13: Fault Event Register
BIT
Enable
bit name
Fault symbol Bit Set condition Bit reset condition
0 (LSB) Spare bit SPARE
1 AC Fail AC
2 Over Temperature OTP
3 Foldback FOLD
4 Over Voltage OVP
5 Shut Off SO
6 Output Off OFF
7(MSB) Enable ENA
Fault condition occurs
and it is enabled.
The fault can set a bit,
but when the fault
clears the bit remains
set.
Entire Event Register is cleared
when user sends “FEVE?”
command to read the register.
“CLS” and power-up also clear
the Fault Event Register.
C. Status Enable Register (SENA nn, SENA?)
The Status Enable Register is set by the user to enable SRQs from changes in power
supply status.
Table 8-14: Status Enable Register
BIT Status name Status symbol Bit Set condition Bit reset condition
0 (LSB)
Constant Voltage
CV
1
Constant Current
CC
2
No Fault
NFLT
3
Fault active
FLT
User command:
“SENA nn” is
received, where nn is
hexadecimal bits.
User command: “SENA nn” is
received, where nn is
hexadecimal bits.
If “nn”=00, no SRQ is sent when
there is a change in Status
Condition Register.
4
Auto-Restart enabled
AST Always zero Always zero
5
Fold enabled
FDE Always zero Always zero
6
Spare
Spare Always zero Always zero
7 (MSB)
Local Mode
LCL
“SENA nn”
command
“SENA nn” command
