EXcel4 Controller Page 17
2.8 Door sensors
Most door sensors have contacts that are closed when the door is closed. If fitting one
where the opposite is true, make the appropriate selection in EXgarde.
If no door sensor is to be fitted then the factory fitted link should be left in place otherwise
the on-board buzzer will start to sound shortly after powering up EXcel 4 (typically 15
seconds after as this is the onboard local alarm for door ajar feature
EXcel terminal
Function
22
Door 1 Door sense input
23
Door 1 Door sense 0V
36
Door 2 Door sense
37
Door 2 Door sense 0V
49
Door 3 Door sense input
50
Door 3 Door sense 0V
55
Door 4 Door sense
56
Door 4 Door sense 0V
2.9 Egress buttons (push to exit)
Use a voltage free contact, simply by shorting the connection between “Egress 0V” and
“Egress input” will activate the relay and its associated door.
EXcel terminal
Function
23
Door 1 Egress 0V
24
Door 1 Egress input
37
Door 2 Egress 0V
38
Door 2 Egress input
50
Door 3 Egress 0V
51
Door 3 Egress input
56
Door 4 Egress 0V
57
Door 4 Egress input
2.10 Inputs
EXcel
terminal
Function
Only available in the
following
configurations
36
Input 3
1 Door
37
0V (for Inputs 3 & 4)
38
Input 4
49
Input 5
1 or 2 Door
50
0V (For inputs 5 & 6)
51
Input 6
55
Input 7
1, 2 or 3 Door
56
0V (For inputs 7 & 8)
57
Input 8
