TDSi EXcel4 User Manual

EXcel4 Controller Page 5
1.4 Cable specifications
Always use suitable cable. Access control systems differ from intruder alarm systems in
that reader and communications cables carry high-speed data signals that can
become distorted or corrupted if inadequate cable is used.
The following tables show the recommended cable types that should be used when
making connections to our EXcel 4 access control systems.
Part №
Cable Type
Cores
Maximum
Distance
Magnetic
Stripe
Reader
5002-0360
Belden 9730
6
60m
Belden 9503
6
25m
OS6C24/Alpha 5096/BICC H8124
6
20m
Screened Alarm Cable
8
Up to 30m
EXprox /
EXprox2
5002-0354
5002-0355
Belden 9730v
6
150m
Belden 9503
6
150m
OS6C24/Alpha 5096/BICC H8124
6
150m
Screened Alarm Cable
8
150m
Optica
5002-0390
5002-0391
Belden 9730
6
150m
Belden 9503
6
150m
OS6C24/Alpha 5096/BICC H8124
6
150m
Screened Alarm Cable
8
150m
Digital IR
5002-1781
5002-1791
Belden 9730
6
150m
Belden 9503
6
150m
OS6C24/Alpha 5096/BICC H8124
6
150m
Screened Alarm Cable
8
150m
MIFARE /
EXsmart2
5002-0433
5002-0434
5002-0435
5002-0436
5002-0440
5002-0441
5002-0442
Belden 9730
6
150m
Belden 9503
6
150m
OS6C24/Alpha 5096/BICC H8124
6
150m
Screened Alarm Cable
8
150m
