TDSi EXcel4 User Manual

EXcel4 Controller Page 44
5.1.5 Readers and doors
EXcel terminal
Function
Alternate use
12
+5V OUT
13
0V OUT
14
Reader 1 MAG-DATA
15
Reader 1 MAG-CLK
16
Reader 1 LED
17
Reader 1 +12V
18
Reader 1 0V
19
Door 1 Lock relay n/c
20
Door 1 Lock relay Common pole
21
Door 1 Lock relay n/o
22
Door 1 Door Sense
23
0V (for Door Sense and Egress)
24
Door 1 Egress
25
Reader 2 MAG-DATA
26
Reader 2 MAG-CLK
27
Reader 2 LED
28
Reader 2&3 +12V
29
Reader 2&3 0V
30
Reader 3 MAG-DATA
31
Reader 3 MAG-CLK
32
Reader 3 LED
33
Door 2 Lock relay n/c
Relay 2 (1, 2 or 3-door configuration)
34
Door 2 Lock relay Common pole
35
Door 2 Lock relay n/o
36
Door 2 Door Sense
Input 3 (1, 2 or 3-door configuration)
37
0V (for Door Sense and Egress)
38
Door 2 Egress
Input 4 (1, 2 or 3-door configuration)
39
+5V OUT
40
+5V OUT
41
Reader 4 MAG-DATA
42
Reader 4 MAG-CLK
43
Reader 4 LED
44
Reader 4 +12V
45
Reader 4 0V
46
Door 3 Lock relay n/c
Relay 3 (1, 2 or 3-door configuration)
47
Door 3 Lock relay Common pole
48
Door 3 Lock relay n/o
49
Door 3 Door Sense
Input 5 (2 or 3-door configuration)
50
0V (for Door Sense and Egress)
51
Door 4 Egress
Input 6 (2 or 3-door configuration)
52
Door 4 Lock relay n/c
Relay 4 (1, 2 or 3-door configuration)
53
Door 4 Lock relay Common pole
54
Door 4 Lock relay n/o
55
Door 4 Door Sense
Input 7 (2 or 3-door configuration)
