Teac LCDV2257DVR - Connecting to an External AV Signal Source(HDMI); Connecting to an External AV Signal Source(AV Output)

15
System Connections
Connecting to an External AV Signal Source(HDMI)
Follow the figure below to connect an HDMI signal source to the HDMI jack on the rear panel of the unit.
After connection, turn on the power of the unit and the external AV signal source. Press INPUT then
direction buttons to select HDMI mode, and then press the ENTER button to confirm.
Connecting to an External AV Signal Source(AV Output)
Use the AV cables to connect the external AV input device to the AV output jacks on the rear panel of the
unit.
After connection, turn on the power of the unit and the external AV signal source. Press INPUT then
direction buttons to select the corresponding mode, and then press the ENTER button to confirm.
