16
System Connections
Connecting to Coaxial Digital Output
This unit is designed with a coaxial digital audio jack, can be connected to the digital amplifier, see the
figure below:
This feature is available only for amplifiers equipped with coaxial digital audio input
connectors.
For TVs with a built-in DVD player (optional) and an amplifier with Dolby Digital decoding
function, set the digital audio signal output format in DVD setup menu to “AC3”.
Connecting a USB Device
This unit is designed with a USB port so that you can connect your USB device and use the build in DVR
record function. It is also used for software upgrade. See figure below:
Make sure that Software file for upgrade is stored in the USB device before connection.
For more information about DVR, please refer to DVR File System (Page 30).
