Teac TE-269 - Technicial Specifications

INSTRUCTION MANUAL
28
TECHNICIAL SPECIFICATIONS
General
Power supply: 11~16V DC
Current consumption: max. 15 A
Maximum power output: 50W x 4 channels (max)
Compatible formats:
DVD/SVCD/VCD/HDCD/MP3/MP4/VIDEO/CDDA/PICTUR
E CDCD-R/-RW/DVD±R/±RW PLAYBACK
Dimensions (W x D x H) /
weight:
165*178*100 mm/2 kg
Working temperature
range:
-20 ℃ - +60 ℃
ESP function: 10 sec. for Audio CD, 120 sec. for MP3
TFT display
Screen size: 6.2 inch
Resolution: 800*480 pixel
Brightness:
460 cd/㎡
Contrast ratio: 500:1
FM Stereo Radio
Frequency range(EUROPE AREA): 87.5 – 108MHz(Step 50KHz)
Frequency range(JAPANESE AREA): 76.0 – 90.0MHz(Step 100KHz)
Frequency range(MIDDLE EAST AREA): 87.5 – 108MHz(Step 50KHz)
Frequency range(AMERICA 1 AREA): 87.5 – 107.9MHz(Step 200KHz)
Frequency range(CHINA AREA): 87.5 – 108MHz(Step 100KHz)
Frequency range(AMERICA 2 AREA): 87.5 – 108MHz(Step 100KHz)
Frequency range(RUSSIA AREA) 87.5 – 108MHz(Step 50KHz)
65-74MHz(Step 10KHz)
Preset memory stations: 18
AM/MW Radio
Frequency range(EUROPE AREA): 522kHz - 1620 KHz(Step 9KHz)
Frequency range(JAPANESE AREA): 522kHz - 1629 KHz(Step 9KHz)
Frequency range(MIDDLE EAST AREA): 531kHz - 1602 KHz(Step 9KHz)
Frequency range(AMERICA 1 AREA): 530kHz - 1710 KHz(Step 10KHz)
Frequency range(CHINA AREA): 522kHz - 1620 KHz(Step 9KHz)
Frequency range(AMERICA 2 AREA): 520kHz - 1710 KHz(Step 10KHz)
Frequency range(RUSSIA AREA) 522kHz - 1620 KHz(Step 9KHz)
Preset memory stations: 12
Audio specification
Frequency response: 20 Hz-20 KHz
TV Color System Color system NTSC/ PAL
Specifications are subject to change without notice. Mass and dimension are
approximate
