3 - Technical Data
Electrical Module Interface
MIO2 Operating Manual, 394934, en, V3.0 3 - 7
3.5 Electrical Module Interface
Supply Ratings
Electrical
Safety
Classification according to EN 61010-1 with regard to electrical safety:
3.6 Requirements
The interface cable is a 9 Pin Sub D CAN-Bus connecting the instrument with the
MIO2.
Warm-up time from
20°C to 45°C
max. 30 min.
Warm-up time from
20°C to 60°C
max. 30 min.
Shaking / rotation fre-
quency
1–8.5 Hz
Linear shaking max. 2 mm amplitude in Y-dimension
Tab. 3-7 Operating ranges, 4 positions
Tab. 3-8 Operating ranges
Connector 9 pin sub D CAN-Bus
Power consumption <150W (90W
a)
)
a) Setup in current limitation mode with the Instrument Software 6.0 or later version.
Voltage range 24V DC (±10%)
Fuses T8A 250V
Tab. 3-9 Electrical specifications (safety)
Overvoltage category II
Tab. 3-10 Software requirements MIO2
6 Positions 4 Positions
Setup & Service Instrument Software V 6.0 or later V 6.4 or later
Application Software Freedom EVOlution V 2.0 or later -
Application Software EVOware V 1.4 SP1 or later V 1.4 SP1 or later
Application Software FluentControl V 1.0 or later
Setup & Service FluentSetup V 1.0 or later
