5 - 6 MIO2 Operating Manual, 394934, en, V3.0

5 - Installation

Incubator Installation

5.2.3 Leveling Incubator

Proceed as follows to level the incubator:

1 Put the incubator (A) on the support plate Fig. 5-4,



5-6.

Note: Make sure that the feet rest precisely in the designated positioning cavities

of the support plate.

2 Use the special tool (D) to adjust the three adjustable incubator feet (E) Fig. 5-



5-6.

Fig. 5-4 Special tool to adjust feet

6 Positions 4 Positions

E EE
