QAM Module Status
Go to “Status” tab and click sub-tab “QAM”. The parameters of this part are derived from the
input signal; they will be gotten automatically when the input signal is available, and cannot be
changed by the user.
Pic-3.1-34
Introduction to the parameters of status:
4-COFDM Module Parameter Setting
Pic-3.1-35
Indicates the total bit rate of input signal, including the valid and null
packet. The unit is Mbps
Indicates the bit rate of valid packet (excluding the null packet). The
unit is Mbps.
Indicates if the physical RF port works (green) or not (red)
