Below are the key parameters:
Parameters
Description
Sub-module1
Display the type of the module
Sub-module2
Display the audio type of the expansion board
Video Source
To select the correct video source for the input from SDI or
CVBS
Video Encode Rate
To set the encode rate for both CBR mode and VBR mode. The
range is 2000 ~ 15000 Kbps.
Video Encode Mode
Select CBR or VBR for the encoding mode
 CBR: Constant Bitrate. The bitrate is fixed at the bitrate set
in the “Video Encode Rate” option
 VBR: Variable Bitrate. The bitrate is floating between the
Maximum and Minimum bitrate range defined by the Max.
and Min. Encode rate options
Video Max Encode Rate
To set the Max encode rate for VBR mode.
Max. Encode Rate: base on the parameter set in “Video Encode
Rate”, it should be input a parameter from 1.75 to 2 times the
encode rate.
Video Min Encode Rate
To set the Min encode rate for VBR mode.
Min. Encode Rate: base on the parameter set in “Video Encode
Rate”, it should be input a parameter from 0 to 0.75 times the
encode rate.
Audio source
To select the correct audio source for the input from SDI or
CVBS
Audio Encode Type
To select the audio encode type
Audio Encode Rate
Select the encoded audio bitrate from 64/128/192/256/320/384
Kbps
Belong to
Configure the audio to the program
Audio Mode
To select the audio mode from Stereo/Joint stereo/Dual
channel/Single channel.
Volume
To adjust the audio volume
Audio PID
To edit the audio PID.
GOP Structure
Base on the GOP structure definition and bandwidth to select
an appropriate parameter
Frame Rate
To select correct frame rate according to the input source. The
frame rate should be the same as that of input source
Video Standard
Select the encode video standard
PCR PID
To edit the PCR PID
Video PID
To edit the Video PID
PMT PID
To edit the PMT PID
Service ID
To edit the service ID
Program Name
To edit the program name
Provider Name
To edit the provider name
After setting all the parameters, you should press ‘Set’ button to save the settings.
