Below are the key parameters:
Parameters
Description
Sub-module 1
Display the type of the module
Sub-module 2
Display the audio type of the expansion board
Video Source
To select the correct video source for the input from SDI or
CVBS.
Video Encode Rate
To set the encode rate for video. The range is 2000 ~ 15000
Kbps
Audio source
To select the correct audio source for the input from SDI or
CVBS
Audio Encode Type
To select the audio encode type
Audio Encode Rate
Select the encoded audio bitrate from 64/128/192/256/320/384
Kbps
Belong to
Configure the audio to the program
Audio Mode
To select the audio mode from Stereo/Joint stereo/Dual
channel/Single channel.
Volume
To adjust the audio volume
Audio PID
To edit the audio PID.
GOP Structure
Base on the GOP structure definition and bandwidth to select an
appropriate parameter
GOP Size
Base on the GOP structure definition and bandwidth to input an
appropriate parameter
Aspect Ratio
Select the encode aspect ratio
Video Standard
Select the encode video standard
PCR PID
To edit the PCR PID
Video PID
To edit the video PID
PMT PID
To edit the PMT PID
Service ID
Default values of the service ID.
Provider Name
To edit the provider name
Program Name
To edit the program name
After setting all the parameters, you should press ‘Apply’ button to save the settings.
 Status
Go to “Status” tab and click sub-tab “SD-Encoder_AV/SDI”. The parameters of this part are
derived from the input signal; they will be gotten automatically when the input signal is available,
and cannot be changed by the user.
