Technalogix TP1000 - HD H.264 HDMI Encoder Setup

55
Pic-3.1-49
3.1.4.10 HD H.264 HDMI Encoder Module
The HD H.264 HDMI Encoder Module supports encoding 2 HDMI channels simultaneously.
 Setting
Pic-3.1-50
Parameters
Description
Port#(T)
Indicates the total bit rate of input signal, including the valid and null
packet. The unit is Mbps
Port#(E)
Indicates the bit rate of valid packet (excluding the null packet). The
unit is Mbps.
VideoResolution
the resolution of input video
