56
Pic-3.1-51
Below are the key parameters:
Parameters
Description
Encode Mode
Select CBR or VBR for the encoding mode.
 CBR: Constant Bitrate. The bitrate is fixed at the bitrate
set in the “Video Encode Rate” option.
 VBR: Variable Bitrate. The bitrate is floating between the
Maximum and Minimum bitrate range defined by the Max.
and Min. Encode rate options.
Video Max Encode Rate
To set the Max encode rate for VBR mode.
Max. Encode Rate: base on the parameter set in “Video
Encode Rate”, it should be input a parameter from 1.75 to 2
times the encode rate.
Video Min Encode Rate
To set the Min encode rate for VBR mode.
Min. Encode Rate: base on the parameter set in “Video
Encode Rate”, it should be input a parameter from 0 to 0.75
times the encode rate.
Video Encode Rate
To set the encode rate for both VBR mode and CBR mode.
The range is 6000 ~ 20000 Kbps.
Audio Encode Rate
Select the encoded audio bitrate from 64/128/192/256/320/384
Kbps
Total Encode Rate
The total encode rate of video and audio contents. Calculated
