Technalogix TP1000 - MPEG4 to MPEG2 Transcoder (TC2) Setup

66
 Status
Pic-3.1-63
Introduction to the parameters of status:
Note:（1） Each transcoder module has 4 channels (channel1 to channel 4), each channel
can only transcode 1 program.
(2) Channel 1 and channel 3 can transcode input signal to SD or HD program,
channe2 and channel 4 can only transcode input signal to SD program.
3.1.4.13 MPEG4 to MPEG2 (TC2) Transcoder Module
The MPEG4 to MPEG2 transcoder module supports transforming two internal MPEG-4 HD or
four MPEG-4 SD programs within the equipment to MPEG2 SD format simultaneously.
The configuration page of this module includes two parts:
Setting: set the parameters for receiving the input signal.
Status: indicates the basic parameter and locking status of input signal.
Parameters
Description
Port#(T)
Indicates the total bit rate of input signal, including the valid and null
packet. The unit is Mbps
Port#(E)
Indicates the bit rate of valid packet (excluding the null packet). The
unit is Mbps.
FirmwareIniStatus
the status indicates if the firmware is initiated successfully
