Technaxx TX-23 User Manual

5. Video Surveillance (Control Panel)
CAUTION: some function is only for special camera!
(0) Cruise (ON/OFF): Set cruise on, the camera will auto move rotate.
(1) Optical zoom: control camera optical zoom +/-, only for the camera
has optical zoom lens.
(2) Digital Zoom: software support 4x digital zoom
(3) Aperture switch: set camera aperture big or small
(4) Capture: snap picture
(5) Record: Record video on computer
(6) Listen: listen to the camera audio on computer
(7) Talk: talk with camera on computer
(8) Set motion detection area: set the motion area (only for cameras which
support motion area, and for this TX-23 means the whole area!)
Set alarm sensitivity and set
area (press left button and move
to set area)

Technaxx TX-23 Specifications

General

Type	IP security camera
PTZ control	No
Alarm input/output	Yes
Placement supported	Indoor
Connectivity technology	Wired & Wireless
Form factor	Dome
Mounting type	Ceiling/wall
Product color	Black
Maximum resolution	- pixels
Supported video modes	-
Video formats supported	M-JPEG
Angle of rotation	355 °
Minimum illumination	0.5 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Optical zoom	- x
LED type	IR
Night vision distance	10 m
Number of illumination LEDs	10
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP / IP
Ethernet LAN (RJ-45) ports	1
Audio formats supported	ADPCM
DC output current	2 A
Power consumption (typical)	4 W
Operating temperature (T-T)	-5 - 55 °C
Minimum RAM	1024 MB
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	110 mm
Width	100 mm
Height	130 mm
Weight	282 g
